Texas Instruments Buffer and Line Driver, Open Drain, Non-Inverting, 5-Pin SOT-23 Package SN74LVC1G07DBVT

Texas Instruments SN74LVC1G07DBVT is a high-performance Buffer and Line Driver IC designed with open drain and non-inverting output functionality. It belongs to the 74LVC family of low-voltage CMOS logic devices optimized for low power consumption and high speed. The device is housed in a small 5-pin SOT-23 surface-mount package making it suitable for space-constrained industrial and commercial electronics applications.

Operating voltage ranges from 1.65V up to 5.5V with tolerance for 5V input levels, enabling compatibility with LVTTL/TTL input standards and LVCMOS outputs. With a fast propagation delay of only 4.2 ns at load capacitance, it supports timely signal buffering and driving in complex circuits. The supply current is minimal at 10 μA, contributing to power efficiency.

It is designed to operate reliably over a wide temperature range from −40°C to +125°C, meeting automotive quality and temperature standards (AEC-Q100), thus suitable for automotive and industrial environments. The device supports a maximum output drive of 32 mA, allowing it to drive different line loads effectively.

The compact SOT-23 package measures 3.05 mm in length, 1.75 mm in width, and 1.45 mm in height, facilitating integration into densely packed PCBs. This model is ideal for line interface applications such as signal buffering, line driving, and logic interfacing in embedded systems, communication equipment, and power management circuits.

Operates from 1.65V to 5.5V supply voltage range. Low supply current of 10 μA enhances power efficiency. Propagates signals with a delay time of 4.2 ns at capacitive load. Maximum low-level output current rating of 32 mA for robust driving capabilities.

Wide operating temperature range of −40°C to +125°C. Meets automotive AEC-Q100 standard ensuring high reliability. Compact 5-pin SOT-23 surface mount package for space-sensitive applications. Compatible with LVTTL/TTL inputs and LVCMOS outputs.

This product is part of the Texas Instruments 74LVC family that leverages silicon gate CMOS technology. It is characterized by low power consumption and is widely adopted in industrial, commercial, automotive, and laboratory electronics.
