Texas Instruments Operational Amplifier 2.2 MHz 8-Pin SOIC Surface Mount TLC2272AIDR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | TLC2272AIDR |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | TLC2272 |
| Output Current | 50mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS, REACH |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 8V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 2.2MHz |
| Input Bias Current | 800 pA |
| Vos - Input Offset Voltage | 1.5 mV |
| Slew Rate | 3.6V/μs |
Key Features
- Features a dual channel configuration in a compact SOIC surface mount package.
- Operates over a supply voltage range of 5V to 8V, suitable for various power environments.
- Maintains low input bias current of 800 pA ensuring precision in signal amplification.
- Offers a fast slew rate of 3.6 V/μs for quick response to input signal changes.
- Wide operating temperature range from -40°C to 125°C suitable for automotive and industrial uses.
- Includes an input offset voltage of 1.5 mV and output current capability of 50 mA.
- Complies with RoHS and REACH environmental standards for safe usage.
- Designed for reliable operation meeting AEC-Q100 automotive quality standards.
Product Description
Texas Instruments TLC2272AIDR is an advanced operational amplifier featuring a 2.2 MHz gain bandwidth product housed in an 8-pin SOIC package designed for surface mount applications. This dual-channel LinCMOS op amp delivers precision signal processing with a minimal input bias current of 800 pA and a low input offset voltage of 1.5 mV, making it suitable for high accuracy analog signal conditioning.
The device operates efficiently within a supply voltage range of 5 to 8 volts and supports an output current up to 50 mA. Its fast slew rate of 3.6 V/μs provides rapid response to input changes, ideal for dynamic signal environments in industrial and automotive applications.
Engineered to perform reliably across wide temperature ranges from -40°C to 125°C, this amplifier complies with AEC-Q100 automotive standards, ensuring robust operation in harsh conditions. It also meets RoHS and REACH directives, underscoring its environmental compliance for green electronics manufacturing.
The compact height of 1.58 mm, length of 4.9 mm, and width of 3.91 mm make the TLC2272AIDR suitable for space-constrained designs. The surface mount SOIC package facilitates efficient PCB assembly and integration.
Dual channel operational amplifier optimizing compact and efficient circuit design. Wide voltage operation from 5V to 8V supports varied power supply configurations. Precision input characteristics with a low bias current and offset voltage.
Fast slew rate enhances performance in signal conditioning and amplification applications. Wide operating temperature range caters to industrial, automotive, and laboratory environments. Compliance with RoHS, REACH, and AEC-Q100 standards ensures quality and environmental safety.
This product is ideal for electronics development in industrial machinery control, automotive systems, instrumentation, and general analog signal processing. Designers benefit from its reliable performance, size efficiency, and compliance with rigorous standards.
Explore the extensive range of Texas Instruments amplifiers and Operational Amplifiers in the EnvMart catalog to source quality components for precision electronics design and manufacturing.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 2.2 MHz, allowing for effective signal amplification in various applications.
It operates within a supply voltage range of 5V to 8V, making it suitable for various power environments.
This operational amplifier can provide an output current of up to 50 mA, which is adequate for many signal conditioning applications.
The input bias current is 800 pA, ensuring precision in signal amplification.
It operates effectively across a wide temperature range from -40°C to 125°C, suitable for both automotive and industrial applications.
The input offset voltage is 1.5 mV, which contributes to its precision in analog signal processing.
It features a fast slew rate of 3.6 V/μs, allowing for quick response to input signal changes.
This operational amplifier is housed in an 8-pin SOIC surface mount package, facilitating efficient PCB assembly.
It complies with RoHS and REACH environmental standards, ensuring safe usage in electronic applications.
This model meets the AEC-Q100 automotive quality standards, ensuring reliable operation in automotive applications.
The dimensions are 1.58 mm in height, 4.9 mm in length, and 3.91 mm in width, making it suitable for space-constrained designs.
This operational amplifier features a dual channel configuration, optimizing circuit design for various applications.
