Abracon 8 MHz ±50 ppm Surface Mount 4-Pin Crystal Unit 1.1 mm Height 5 mm Length 3.2 mm Width ABM3B-8.000MHZ-10-D1G-T

Abracon ABM3B-8.000MHZ-10-D1G-T is an 8 MHz crystal unit designed for surface mount applications requiring precision and stability. Featuring a frequency tolerance of ±50 ppm, this crystal unit delivers reliable performance for demanding communication and electronic applications.

The crystal unit comes packaged in a compact ceramic surface mount package with dimensions of 5 mm length, 3.2 mm width, and a low profile height of 1.1 mm. It is a 4-pin device with a load capacitance of 10 pF and series resistance rating of 200 Ω, operating in fundamental mode for accurate frequency reference.

Engineered with a ceramic package and metal lid, the unit ensures high durability and precision. It is suitable for a wide range of industrial and commercial electronics, including cellular telephones, pagers, test instruments, high density and wireless devices, as well as PCMCIA applications.

Operating temperature range spans from -10°C to 60°C, ensuring stable operation in varying environments. The component is RoHS compliant, meeting environmental and safety regulations for use in modern electronic assemblies.

This Abracon crystal unit can be easily reflow soldered onto PCBs, supporting efficient manufacturing in industrial electronics assembly lines. Standard frequency of 8 MHz with ±50 ppm frequency tolerance. Surface mount type with 4 pins for easy PCB integration.

Compact dimensions measuring 5 mm length, 3.2 mm width, and 1.1 mm height. Load capacitance of 10 pF ensures stable oscillator operation. Operates reliably between -10°C and 60°C temperature range. Series resistance of 200 Ω with fundamental mode operation.

RoHS compliant ceramic package with metal lid for enhanced reliability. Ideal for cellular telephones, wireless devices, pagers, and test equipment. Supports automated reflow soldering processes in manufacturing. Explore the wide range of precision Crystal Units available in the Electronics Components category at EnvMart for your industrial, manufacturing, and laboratory needs.
