Abracon 22.1184 MHz Crystal Unit ±30 ppm Frequency Tolerance Through Hole Mount HC-49-US Package ABLS-22.1184MHZ-B2-T

Abracon ABLS-22.1184MHZ-B2-T Crystal Unit is designed for high precision frequency control applications in electronic devices. Operating at a standard frequency of 22.1184 MHz with a tight frequency tolerance of ±30 ppm, this crystal unit offers stable and reliable oscillation performance.

The component features a through hole mounting style using an HC-49-US package, which measures 11.5 mm in length, 4.7 mm in width, and 4.2 mm in height, providing a compact footprint suitable for various PCB layouts.

Load capacitance of 16 pF is optimized to maintain signal integrity, while the series resistance of 40 Ω ensures low conductive losses. The crystal is capable of operating over a temperature range from 0°C to 70°C, maintaining frequency stability within ±50 ppm, making it suitable for applications exposed to varying thermal conditions.

Manufactured to comply with RoHS standards, this crystal is lead free and environmentally friendly. Its 2-pin configuration facilitates straightforward integration into circuits and systems. The unit is packaged in tape and reel format, supporting efficient automated assembly processes commonly used in mass production environments.

This crystal unit is ideal for electronic applications including computers, modems, microprocessors, communication devices, and wireless equipment requiring stable clock generation and precise timing.

Standard frequency of 22.1184 MHz ensures precise timing. Through hole mount type for secure PCB installation. Load capacitance is 16pF supporting stable oscillations. Compact dimensions of 11.5 mm length, 4.7 mm width, and 4.2 mm height.

Operates reliably from 0°C to 70°C ambient temperature. Frequency stability maintains ±50 ppm over operating temperature. Series resistance of 40 Ω optimizes signal integrity. RoHS compliant and lead-free construction for eco-friendly use.

Supplied in tape & reel packaging suited for automated assembly. Pin count of 2 ensures simple connectivity.

For industrial, laboratory, electronic manufacturing, and communication system design needs, Abracon crystal units deliver performance and compliance. Explore more Crystal Units and oscillators for varied frequency and package requirements on EnvMart.
