Texas Instruments Operational Amplifier 4-Channel 1 MHz Gain Bandwidth, 14-Pin SOIC Package LM2902M/NOPB
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.45mm |
| Length | 8.64mm |
| Model | LM2902M/NOPB |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | LM2902-N |
| Output Current | 40mA |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pin Count | 14 |
| Maximum Supply Voltage | 26V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 1MHz |
| Input Bias Current | 500 nA |
| Vos - Input Offset Voltage | 10 mV |
| Slew Rate | 0.5V/μs |
| Input Offset Current | 200 nA |
Key Features
- Features a gain bandwidth product of 1 MHz for accurate amplification.
- Supports voltage supply range from 5V minimum up to 26V maximum.
- Includes low input bias current of 500 nA and input offset current of 200 nA.
- Operates reliably between temperatures of -40°C to 85°C.
- Compact SOIC package with dimensions 8.64 mm length, 3.91 mm width, and 1.45 mm height.
- Provides an output current capability of 40 mA suitable for various signal amplification needs.
- Designed for general purpose applications with RoHS compliance.
- Slew rate of 0.5 V/μs ensures moderate signal response speed.
Product Description
Texas Instruments LM2902M/NOPB is a highly reliable operational amplifier designed for diverse industrial and electronics applications. This 4-channel Operational Amplifier offers a gain bandwidth product of 1 MHz, making it suitable for general-purpose signal amplification in both low power and high performance circuits.
The device is housed in a compact 14-pin Small Outline Integrated Circuit (SOIC) package optimized for surface mounting on printed circuit boards, with precise dimensions of 8.64mm in length, 3.91mm in width, and 1.45mm in height. It supports a wide supply voltage range from 5V to 26V, ideal for various operating environments.
Key electrical characteristics include a low input bias current of 500 nA, an input offset current of 200 nA, and an input offset voltage of 10 mV, ensuring accurate input signal processing. The output current capability of 40 mA allows effective driving of loads while maintaining signal integrity. A moderate slew rate of 0.5 V/μs aids in stable signal transitions.
Operating temperature range from -40°C to 85°C makes the LM2902M/NOPB suitable for demanding industrial and commercial applications. This device complies with RoHS standards for environmental safety, providing an eco-friendly solution for electronic manufacturing.
The LM2902M/NOPB is part of the LM2902-N series, well-behaved in general purpose amplifier applications. It is favored in instrumentation, signal conditioning, and control systems due to its reliability and ease of integration into standard PCB layouts.
Gain bandwidth product of 1 MHz ensures effective amplification. Wide supply voltage range supports various power systems. Low input bias and offset currents enhance precision. Robust operating temperature range for industrial use.
Compact 14-pin SOIC package facilitates surface mount assembly. Compliance with RoHS provides environmental assurance. Designed for multi-channel use with four independent amplifiers. Moderate slew rate for signal stability.
Output current rating supports diverse applications.
Ideal for use in industrial electronics, laboratory instrumentation, and general signal amplification tasks. For further component details and related products, customers may browse the Electronics & Electricals category on EnvMart for trusted offerings from Texas Instruments and other top semiconductor manufacturers.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of the LM2902M/NOPB is 1 MHz, making it suitable for effective signal amplification in various applications.
This operational amplifier supports a supply voltage range from 5V to 26V, accommodating various power systems.
The LM2902M/NOPB is housed in a 14-pin SOIC package with dimensions of 8.64 mm in length, 3.91 mm in width, and 1.45 mm in height.
It has an output current capability of 40 mA, suitable for driving various loads while maintaining signal integrity.
This operational amplifier operates reliably within a temperature range of -40°C to 85°C, making it suitable for industrial applications.
The input bias current for this model is 500 nA, which helps ensure accurate signal processing.
The slew rate of the LM2902M/NOPB is 0.5 V/μs, which supports stable signal transitions.
This operational amplifier features four independent channels, allowing for multi-channel signal amplification.
The input offset voltage is specified at 10 mV, which contributes to the precision of the amplifier.
Yes, the LM2902M/NOPB complies with RoHS standards, ensuring it meets environmental safety requirements.
It is designed for general-purpose applications, including instrumentation, signal conditioning, and control systems.
The input offset current is 200 nA, which aids in maintaining accurate signal processing.
