Texas Instruments Operational Amplifier, 50 kHz Gain Bandwidth, 15.5V Max Supply, 8-Pin SOIC Package LMC6462BIM/NOPB
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.45mm |
| Length | 4.9mm |
| Model | LMC6462BIM/NOPB |
| Width | 3.9mm |
| Mount Type | Surface |
| Series | LMC6462 |
| Output Current | 19mA |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Pin Count | 8 |
| Maximum Supply Voltage | 15.5V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 50kHz |
| Input Bias Current | 10 pA |
| Vos - Input Offset Voltage | 3.7 mV |
| Slew Rate | 0.03V/μs |
| Input Offset Current | 5 pA |
Key Features
- Dual-channel operational amplifier designed for low power applications.
- Supports a wide supply voltage range from 5V up to 15.5V.
- Features low input bias current of 10 pA and input offset current of 5 pA.
- Low slew rate of 0.03 V/μs ensures precision signal amplification.
- Temperature operating range from -40°C to 85°C for reliable performance.
- Compact 8-pin SOIC package with dimensions 4.9 mm length by 3.9 mm width and 1.45 mm height.
- Provides output current capacity up to 19 mA suitable for various industrial and electronic applications.
- CMOS technology enhances stability and reduces power consumption.
Product Description
Texas Instruments LMC6462BIM/NOPB operational amplifier is a dual-channel CMOS amplifier designed for precision and low power industrial and electronic applications. Featuring a gain bandwidth product of 50 kHz and operating voltage range from 5V to 15.5V, this device supports surface mount placement with its 8-pin SOIC package.
It delivers low input bias and offset currents, at 10 pA and 5 pA respectively, ensuring accurate amplification in sensitive analog circuits. With a low slew rate of 0.03 V/μs, it is ideal for applications requiring signal integrity and precision.
The amplifier operates reliably within a temperature range of -40°C to 85°C, enabling use in diverse environmental conditions commonly found in industrial electronics and instrumentation. The compact physical size (length 4.9 mm, width 3.9 mm, height 1.45 mm) supports agile integration in space-constrained PCB designs.
Output current capability of 19 mA makes this device suitable for driving loads in measurement, control, and signal conditioning circuits. It is not specifically designed for automotive standards but is widely applied in laboratory instrumentation, industrial control systems, and power electronics.
Dual channel operational amplifier with CMOS technology. Gain bandwidth of 50 kHz for moderate frequency applications. Supply voltage range from 5V to 15.5V for flexibility. Low input bias and offset currents for precision analog signals.
Compact SOIC 8-pin surface mount package for easy PCB assembly. Operating temperature range suitable for industrial environments. Moderate output current supporting a wide range of applications. Reliable performance in electronic component and semiconductor-based designs.
This Texas Instruments Operational Amplifier is essential for designers requiring reliable, low noise amplification in electronic, laboratory, and industrial automation systems. Browse our electronics and semiconductors category for more high-quality amplifiers and components at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 50 kHz, making it suitable for moderate frequency applications.
This model operates within a supply voltage range from 5V to 15.5V, providing flexibility for various applications.
It has an output current capacity of up to 19 mA, which is suitable for driving loads in measurement and control circuits.
The dimensions of the 8-pin SOIC package are 4.9 mm in length, 3.9 mm in width, and 1.45 mm in height.
The operational amplifier operates reliably within a temperature range of -40°C to 85°C, suitable for industrial environments.
The input bias current is specified at 10 pA, which helps ensure accurate amplification in sensitive analog circuits.
The input offset current is 5 pA, contributing to the precision of the amplifier's performance.
The slew rate of this operational amplifier is 0.03 V/μs, which is important for maintaining signal integrity.
This model features two channels, allowing for dual-channel applications in various circuits.
It utilizes a surface mount type, facilitating easy integration into PCB designs.
The input offset voltage is specified at 3.7 mV, which is critical for precision applications.
This operational amplifier is designed using CMOS technology, which enhances stability and reduces power consumption.
