Crydom CW Series Solid State Relay, 50 A Load, Panel Mount, 280 Vrms Load, 32V Control CWD2450P

The Crydom CWD2450P CW Series Solid State Relay is a high-performance device designed for demanding industrial control applications. It provides a robust 50 A maximum load current capacity and 280 Vrms maximum load voltage, ideal for switching AC loads with panel mount convenience.

Equipped with an aluminium baseplate that offers corrosion resistance and enhanced heat dissipation, this solid state relay ensures longevity and reliable performance even in harsh environments. The flame-retardant housing adds an extra layer of safety by reducing fire risk during electrical faults.

The relay operates with control voltages ranging from 3 V DC to 32 V DC, making it highly adaptable to various control systems. Its screw terminal type ensures stable and secure electrical connections, essential for industrial settings.

Featuring zero voltage switching function, it significantly minimizes electrical noise during load switching, improving system stability and extending device life. The device is certified to meet CE and RoHS standards, indicating compliance with European safety and environmental regulations.

Thanks to an IP20 enclosure rating, the relay is finger-safe and protected against entry of solid objects larger than 12 mm, suitable for safeguarded industrial panels. Its operational temperature range from -40°C to 80°C allows use in diverse environmental conditions, from cold storage to heated manufacturing floors.

The compact dimensions of 44.5 mm length, 30.9 mm height, and 22 mm width facilitate easy panel mounting without compromise on space. The relay’s SCR output type and SPST contact configuration provide reliable single-pole single-throw switching for precise control tasks.

This Crydom solid state relay is electromagnetically compatible, minimizing interference risks to nearby sensitive electronic equipment in applications such as data centers, industrial power supplies, and automation systems.

The relay offers a quick turn-on and turn-off time of half a cycle for fast response to control signals. Its durable design ensures minimal wear and tear, maximizing service life in industrial use cases. Ideal for industrial, automation, electrical panels, and manufacturing control circuits requiring robust load switching.

Set your industrial control systems up for success with the Crydom CWD2450P Solid State Relay, combining high load capacity with advanced safety and reliability features. Explore more industrial relays at EnvMart for comprehensive automation solutions.
