STMicroelectronics 1-Element Bi-Directional TVS Diode 1.5 kW Peak Pulse Power Surface Mount SMC Package SM15T15CA
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 2.45mm |
| Length | 7.15mm |
| Model | SM15T15CA |
| Width | 6.25mm |
| Mount Type | Surface |
| Series | SM15T TVS |
| Maximum Operating Temperature | 150°C |
| Package Type | SMC |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 27.2V |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 14.3V |
| Maximum Reverse Stand-off Voltage Vwm | 12.8V |
| Peak Pulse Power Dissipation Pppm | 1.5kW |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 368A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Designed for bi-directional transient voltage suppression.
- Offers a peak pulse power dissipation of 1.5 kW for robust protection.
- Operates within a temperature range of -55°C to 150°C ensuring reliability.
- Has a minimum breakdown voltage of 14.3 V and a maximum reverse stand-off voltage of 12.8 V.
- Features a compact SMC surface mount package measuring 7.15 mm length by 6.25 mm width.
- Clamping voltage is rated at 27.2 V to protect against voltage spikes.
- Maximum peak pulse current capability of 368 A for surge current handling.
- Low maximum reverse leakage current of 1 μA minimizes power loss.
Product Description
STMicroelectronics SM15T15CA is a single element, bi-directional transient voltage suppression (TVS) diode designed to protect sensitive electronics from voltage spikes and transient surges.
This TVS diode offers a peak pulse power dissipation of 1.5 kW with a compact and robust 2-pin SMC surface mount package suitable for automated PCB assembly. It supports a minimum breakdown voltage of 14.3 V and a maximum reverse stand-off voltage of 12.8 V, with a clamping voltage of 27.2 V, ensuring reliable transient voltage protection.
The device operates effectively within a temperature range from -55°C up to 150°C, making it ideal for a wide range of industrial and commercial applications. It features a maximum peak pulse current of 368 A and low leakage current of 1 μA, ensuring minimal impact on normal circuit operation.
The diode's physical dimensions are compact, with a length of 7.15 mm, width of 6.25 mm, and height of 2.45 mm, suitable for space-constrained electronics design. Single element configuration provides precise voltage suppression, enhancing durability and performance.
This component is widely used in electronic circuits for protection in industrial automation, power management, automotive electronics (non-automotive standard), telecommunications, and consumer electronics equipment.
Designed for bi-directional transient voltage suppression. Offers a peak pulse power dissipation of 1.5 kW for robust protection. Operates within a temperature range of -55°C to 150°C ensuring reliability. Has a minimum breakdown voltage of 14.3 V and a maximum reverse stand-off voltage of 12.8 V.
Features a compact SMC surface mount package measuring 7.15 mm length by 6.25 mm width. Clamping voltage is rated at 27.2 V to protect against voltage spikes. Maximum peak pulse current capability of 368 A for surge current handling.
Low maximum reverse leakage current of 1 μA minimizes power loss. Single element chip design for precise voltage suppression. Compliant with standard electronic component specifications for surface mounting. Explore more products in the TVS Diode category for advanced circuit protection solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The STMicroelectronics SM15T15CA offers a peak pulse power dissipation of 1.5 kW, providing robust protection against voltage spikes.
It operates effectively within a temperature range of -55°C to 150°C, ensuring reliability across various applications.
The SMC package of this diode measures 7.15 mm in length, 6.25 mm in width, and 2.45 mm in height, making it suitable for space-constrained designs.
The clamping voltage is rated at 27.2 V, which helps protect against voltage spikes in electronic circuits.
This model has a maximum peak pulse current capability of 368 A, allowing it to handle significant surge currents.
The minimum breakdown voltage is 14.3 V, which is essential for effective voltage suppression in circuits.
The maximum reverse stand-off voltage is 12.8 V, providing a safe operating limit for the diode.
It features a low maximum reverse leakage current of 1 μA, which minimizes power loss during normal operation.
This model uses a single element configuration, which provides precise voltage suppression for sensitive electronics.
The SMC package has a pin count of 2, suitable for surface mount applications.
This diode is widely used in industrial automation, power management, automotive electronics, telecommunications, and consumer electronics equipment for protection against voltage spikes.
The country of origin for the STMicroelectronics SM15T15CA is India.
