Nexperia Schottky Barrier Diode 40 V 120 mA Single 3-Pin Surface Mount SOT-23 BAS40-04,215

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Schottky Barrier Diode 40 V 120 mA Single 3-Pin Surface Mount SOT-23 BAS40-04,215

Name: Nexperia Schottky Barrier Diode 40 V 120 mA Single 3-Pin Surface Mount SOT-23 BAS40-04,215
Brand: Nexperia
SKU: 334682
Price: 0.08 USD
Availability: InStock



Category Schottky Barrier Diode Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1mm
Length	3mm
Model	BAS40-04,215
Width	1.4mm
Mount Type	Surface
Series	BAS40-04
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Pin Count	3
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	120mA
Peak Reverse Repetitive Voltage Vrrm	40V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	10μA
Peak Non-Repetitive Forward Surge Current Ifsm	200mA
Maximum Forward Voltage Vf	380mV
onsemi 40 V 120 mA Diode Schottky 3-Pin SOT-23 BAS40-04LT1GBrand	onsemi

Key Features

Maximum continuous forward current of 120 mA ensures reliable performance in low current applications.
Peak reverse repetitive voltage rating of 40 V provides robust reverse voltage protection.
Compact SOT-23 package with 3 pins allows space-efficient PCB mounting.
Low forward voltage of 380 mV minimizes power loss and enhances efficiency.
Wide operating temperature range from -65°C to 150°C supports automotive and industrial environments.
Designed according to automotive standard AEC-Q101 for high reliability.
Low leakage current and negligible power switching losses ensure energy efficiency.
Sourced from China with consistent quality and performance.

Product Description

The Nexperia BAS40-04,215 is a high-efficiency Schottky barrier diode designed for industrial, automotive, and electronic applications requiring low voltage drop and high-speed switching characteristics. This diode features a maximum continuous forward current rating of 120 mA and a peak reverse repetitive voltage of 40 volts, making it suitable for low current rectification and protection circuits.

The device is enclosed in a compact surface mount SOT-23 package with 3 pins, measuring 3 mm in length, 1.4 mm in width, and 1 mm in height. Its design emphasizes ultra-small size and low profile, suitable for modern compact electronic assemblies.

Key electrical features include a low forward voltage of 380 mV to reduce power dissipation, a peak non-repetitive forward surge current rating of 200 mA, and a minimum operating temperature of -65°C with a maximum operating temperature of 150°C. These ratings make the BAS40-04,215 compliant with the AEC-Q101 automotive standard, ensuring reliability in harsh environments.

The diode exhibits low leakage current and minimal capacitance, resulting in negligible power switching losses. Its single diode configuration is optimized for fast recovery and excellent efficiency in power management and signal rectification circuits.

Maximum continuous forward current: 120 mA. Peak reverse repetitive voltage: 40 V. Surface mount SOT-23 package, 3 pins. Low forward voltage drop of 380 mV. Operating temperature: -65°C to 150°C. Automotive standard: AEC-Q101.

Low leakage current and power losses. Compact package dimensions: Length 3 mm, Width 1.4 mm, Height 1 mm.

Its robust electrical and thermal specifications make the Nexperia BAS40-04,215 ideal for use in applications such as power supplies, automotive electronics, signal and power rectification, and protection circuits in industrial and consumer electronic devices.

Browse other semiconductor and discrete component solutions in the Schottky Barrier Diode category at EnvMart for complementary products and optimized design choices.
