TDK Flange EMC Filter 20 A 250V ac/dc 60Hz Screw Termination 1 Phase B84142A0020R000

TDK B84142A0020R000 is a flange-type EMC filter designed for single-phase electrical systems, delivering 20 A maximum current and rated for 250V ac/dc at 60Hz operation frequency. This filter provides excellent electromagnetic interference suppression specially optimized for long motor cables in demanding industrial applications such as lifts, conveyor belts, pumps, ventilation systems, and power supply units.

The filter features a two-stage design ensuring very high insertion loss, helping to maintain system integrity and reduce noise effectively. The screw termination and flange mount facilitate secure and stable installation. It operates reliably within a wide temperature range from -25°C to 100°C and has a low leakage current of 7.9 mA, contributing to efficient energy usage.

Compliance with UL1283 and CSA22.2 No. 8 (construction) standards assures safety and quality. The filter’s nominal resistance of 10 mΩ supports dependable electrical performance. Physical dimensions of 105 mm length, 68 mm height, and 121 mm depth allow it to fit compactly into various industrial equipment configurations. Protection rated IP20 means it is suitable for protected indoor environments.

This EMC filter is ideally suited for industrial applications requiring robust EMI suppression including manufacturing, construction, HVAC systems, and water treatment plants. Its compact size and high efficiency make it a preferred choice for engineers demanding reliable electromagnetic interference mitigation.

Compact two-line filter design suitable for electrical systems in lifts and conveyor belts. Provides very high insertion loss optimizing performance for long motor cables under full load. Features flange mount type with screw termination ensuring secure installation.

Operates effectively within a temperature range of -25°C to 100°C. Designed with low leakage current of 7.9 mA for energy-efficient operation. Constructed to meet UL1283 and CSA22.2 No. 8 (construction) standards. Resistant with a nominal resistance of 10 mΩ for reliable operation.

Dimensions are length 105 mm, height 68 mm, depth 121 mm, facilitating compact installation. Ideal for use in pumps, ventilation systems, and power supply units in industrial environments. Protection type rated as IP20, suitable for protected environments.
