Panasonic PCB Signal Relay 5V DC Coil 1A Switching Current DPDT Contact Configuration TQ2-L2-5V

Panasonic TQ2-L2-5V PCB Signal Relay features a 5V DC coil voltage with a double pole double throw (DPDT) contact configuration, providing reliable switching capabilities with a 1A current rating. This relay is engineered for compact PCB mounting with a low profile design that measures just 5mm in height, making it suitable for modern electronic assemblies requiring space-saving components.

With overall dimensions of 14mm length and 9mm width, the relay incorporates gold plated contacts which provide excellent conductivity and low contact resistance at 50 milliohms, ensuring minimal signal loss and enhanced durability over repeated operations. The coil resistance of 125 ohms with a nominal coil power consumption of 200mW supports low energy usage and efficient electromagnetic operation.

This relay is operational within a broad temperature range from -40 degrees Celsius to 70 degrees Celsius, making it suitable for use in various industrial and commercial electronic environments. It is designed for PCB solder mounting and features low thermal electromotive force, aiding in high sensitivity and stable switching performance.

Conforming to RoHS standards and manufactured in Japan, the product promises high quality and environmental safety. It supports switching of AC voltages up to 240V at 1A, making it versatile for signal applications in telecommunications, measurement and quality assurance devices, and other electronic systems requiring reliable relay operation.

The relay’s double pole double throw (DPDT) contacts enable control of two independent circuits. Compact dimensions and low height facilitate integration in tightly packed PCB layouts. Gold plated contacts extend operational life and provide stable electrical connections.

Low coil power consumption supports energy-efficient designs. Wide operating temperature range ensures reliable performance under harsh conditions. RoHS compliance guarantees environmental friendliness and regulatory adherence.

Made in Japan ensuring quality assurance and consistent manufacturing standards. Applications include telecommunications, measurement equipment, and automated control systems.

Explore the wide range of Panasonic electronics and Signal Relay products on EnvMart for industrial, commercial, and laboratory applications requiring precise and dependable relay solutions.
