Panasonic PCB Signal Relay 24V DC Coil, DPDT Contact Configuration TQ2-24V
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 5mm |
| Length | 14mm |
| Model | TQ2-24V |
| Width | 9mm |
| Mount Type | PCB |
| Contact Material | Gold Plated |
| Series | TQ224 |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Terminal type | Solder |
| Contact Resistance | 50mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 2880Ω |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 125V ac |
| Coil Power | 200mW |
| Panasonic PCB Mount Non-Latching Relay, 24V dc Coil, DPDTBrand | Panasonic |
Key Features
- The relay operates at a coil voltage of 24V DC with a coil power consumption of 200mW.
- It has a double-pole double-throw (DPDT) contact configuration suitable for various circuits.
- The compact PCB mount relay measures 14mm in length, 9mm in width, and 5mm in height.
- Designed for switching AC voltages up to 125V and DC voltages up to 30V.
- Featuring gold-plated contacts and low contact resistance of 50mΩ for reliable performance.
- Operates efficiently across a temperature range of -40°C to 70°C.
- Its coil resistance is 2880Ω, ensuring low power consumption and thermal EMF.
- Ideal for applications in communications, measurement, office automation, and industrial machinery.
Product Description
Panasonic TQ2-24V is a high-frequency PCB signal relay designed for low power consumption and high reliability in signal switching tasks. It features a 24V DC coil and a DPDT (Double Pole Double Throw) contact configuration, making it suitable for diverse electronic applications.
The relay complies with JIS C0806 standards and offers a compact size of 14mm length, 9mm width, and 5mm height, which enables high-density PCB mounting. Its gold-plated contacts ensure minimal contact resistance of 50mΩ, guaranteeing precision switching and durability over extended use.
With a coil resistance of 2880Ω and coil power of 200mW, this relay provides low energy consumption and generates minimal thermal electromotive force, approximately 5μV. It operates efficiently within temperature ranges from -40°C up to 70°C, suitable for harsh industrial environments.
Typical applications for the Panasonic TQ2-24V include telecommunications equipment, measurement instruments, office automation systems, and various types of industrial machinery, where reliable signal conditioning and switching are required. The relay supports switching of AC voltages up to 125V and DC voltages up to 30V, providing versatility for many circuit designs.
The relay supports high-frequency operation with a flat, compact body for space-saving PCB assembly. Gold-plated contacts provide excellent conductivity and corrosion resistance. Low coil power consumption contributes to energy-efficient circuit designs.
Wide operating temperature range allows use in diverse climate conditions. Conforms to RoHS standards, ensuring environmentally friendly manufacturing. Suitable for critical industrial, laboratory, and automated control applications.
Compact dimensions enable integration into densely packed PCB assemblies.
This Panasonic TQ2-24V PCB Signal Relay is a dependable component in the electronics and electricals category, ideal for precise and durable switching functions in professional and industrial environments. Explore related relays and contactors in the EnvMart catalogue for comprehensive solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay operates at a coil voltage of 24V DC.
It features a double-pole double-throw (DPDT) contact configuration.
The relay measures 14mm in length, 9mm in width, and 5mm in height.
It supports switching of AC voltages up to 125V and DC voltages up to 30V.
The coil power consumption is 200mW.
The contact resistance is 50mΩ.
It operates efficiently within a temperature range of -40°C to 70°C.
The coil resistance is 2880Ω.
This model is designed for PCB mounting.
It complies with RoHS standards, ensuring environmentally friendly manufacturing.
The contacts are made of gold-plated material, providing excellent conductivity and corrosion resistance.
It is suitable for applications in telecommunications, measurement instruments, office automation, and various types of industrial machinery.
