Texas Instruments Operational Amplifier 6.4 MHz Gain Bandwidth, 8-Pin SOIC, 3-6V TLV2462CD
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | TLV2462CD |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | TLV2462 |
| Output Current | 175mA |
| Maximum Operating Temperature | 70°C |
| Package Type | SOIC |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 6V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 6.4MHz |
| Input Bias Current | 25 nA |
| Vos - Input Offset Voltage | 2.2 mV |
| Slew Rate | 1.6V/μs |
| Input Offset Current | 20 nA |
Key Features
- Operates with a supply voltage range from 3V to 6V ensuring energy efficiency.
- Provides a gain bandwidth product (GBP) of 6.4 MHz for high-frequency signal amplification.
- Includes low input bias current of 25 nA and low input offset current of 20 nA for precision applications.
- Offers a slew rate of 1.6 V/μs supporting rapid response in signal changes.
- Compact dimensions with length 4.9 mm, width 3.91 mm, and height 1.58 mm in a surface mount SOIC package.
- Maximum output current up to 175 mA suitable for various load conditions.
- Conforms to RoHS environmental standards and automotive standard AEC-Q100 for reliability.
- Operating temperature ranges from 0 °C to 70 °C ensuring stable performance in typical ambient environments.
Product Description
Texas Instruments TLV2462CD is a high-performance dual operational amplifier designed for low voltage applications, with a supply voltage operating range between 3V and 6V. The device is housed in an 8-pin SOIC surface-mount package, making it suitable for compact electronics requiring reliable analog signal amplification.
With a gain bandwidth product of 6.4 MHz, the TLV2462CD is capable of amplifying signals accurately at higher frequencies. The low input bias current of 25 nA and input offset current of 20 nA ensure precision in sensitive measurement and control applications across industrial, automotive, and consumer electronics.
This Operational Amplifier offers a slew rate of 1.6 V/μs allowing for quick response to input signal changes, which is critical for dynamic systems. Its maximum output current of 175 mA supports driving moderate loads without compromising performance.
The compact dimensions of 4.9 mm length, 3.91 mm width, and 1.58 mm height facilitate integration into modern miniaturized PCB designs. It complies with RoHS environmental directives, promoting sustainable manufacturing, and meets the automotive standard AEC-Q100, making it suitable for use in automotive and other high-reliability environments.
Typical use cases for TLV2462CD include embedded systems, sensor signal conditioning, industrial control circuits, automotive systems, and other low-voltage analog electronics where precision and reliable performance are paramount.
Operates from 3 V to 6 V supply voltage for flexible power applications. Dual-channel amplifier with 8-pin SOIC package for surface mount technology. Gain bandwidth product of 6.4 MHz supports high-speed signal handling.
Low input bias and offset currents enable precise analog signal processing. Slew rate of 1.6 V/μs for rapid output response. Output current up to 175 mA for driving various loads. Meets RoHS and automotive AEC-Q100 standards for compliance and reliability.
Operating temperature range from 0 °C to 70 °C suitable for typical industrial settings. Explore the comprehensive range of Texas Instruments semiconductor amplifiers in EnvMart for industrial and electronic design applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TLV2462CD has a gain bandwidth product of 6.4 MHz, enabling it to amplify signals accurately at higher frequencies.
This model operates with a supply voltage range from 3V to 6V, allowing for flexible power applications.
The maximum output current of this operational amplifier is 175 mA, suitable for driving various load conditions.
The dimensions of this operational amplifier are 4.9 mm in length, 3.91 mm in width, and 1.58 mm in height.
The slew rate for this model is 1.6 V/μs, which supports rapid response to input signal changes.
This operational amplifier features a low input bias current of 25 nA, which is beneficial for precision applications.
The input offset current for this model is 20 nA, contributing to its precision in sensitive applications.
It conforms to RoHS environmental standards and meets the automotive standard AEC-Q100 for reliability.
The operational amplifier operates within an ambient temperature range from 0 °C to 70 °C, ensuring stable performance in typical environments.
This model is a dual-channel operational amplifier, providing two amplification paths in one package.
The TLV2462CD is housed in an 8-pin SOIC surface-mount package, suitable for compact electronic designs.
Typical use cases for this operational amplifier include embedded systems, sensor signal conditioning, and industrial control circuits.
