Texas Instruments Operational Amplifier 1 MHz 14-Pin PDIP 32V Through Hole LM324N/NOPB
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 5.08mm |
| Length | 19.69mm |
| Model | LM324N/NOPB |
| Width | 6.6mm |
| Mount Type | Through Hole |
| Series | LM324-N |
| Output Current | 40mA |
| Maximum Operating Temperature | 70°C |
| Package Type | PDIP |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 4 |
| Pin Count | 14 |
| Maximum Supply Voltage | 32V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 1MHz |
| Input Bias Current | 500 nA |
| Vos - Input Offset Voltage | 9 mV |
| Input Offset Current | 150 nA |
Key Features
- Features four independent operational amplifiers in a single package.
- Supports supply voltages ranging from 3 V to 32 V.
- Input offset voltage is typically 9 mV for precision applications.
- Operates within the temperature range of 0°C to 70°C.
- Maximum output current capability of 40 mA ensuring reliable drive performance.
- Compact dimensions with a length of 19.69 mm, width of 6.6 mm, and height of 5.08 mm.
- Package type is PDIP supporting standard through-hole PCB assembly.
- Low input bias current of 500 nA and input offset current of 150 nA.
Product Description
Texas Instruments LM324N/NOPB is a high-performance operational amplifier featuring a 1 MHz gain bandwidth product. Packaged in a 14-pin PDIP through-hole mounting type, this component is designed for versatile usage in electronic amplification applications. The amplifier provides four independent operational amplifiers suitable for signal conditioning, filtering, and general analog electronics tasks.
Operating voltage ranges from 3 V minimum to 32 V maximum, making it compatible with a variety of power supplies. The unit offers a typical input offset voltage of 9 mV, alongside low input bias and offset currents, enabling precise analog signal processing with minimal error.
This device operates efficiently in ambient temperatures from 0°C to 70°C, suitable for standard industrial environments. The output current capability of 40 mA supports driving moderately low-impedance loads reliably.
The compact dimensions of 19.69 mm length, 6.6 mm width, and 5.08 mm height facilitate ease of integration into printed circuit boards. The Through Hole PDIP package ensures robust mounting for prototyping and production scale applications.
Commonly applied in industrial automation, laboratory instrumentation, audio systems, and general electronics, the LM324N/NOPB delivers reliable and consistent performance for a broad range of operational amplifier needs.
Features four independent operational amplifiers in one package. Supports supply voltage range of 3 V to 32 V for flexible power options. Minimal input offset voltage and low bias currents for precision. Operates reliably over industrial temperature ranges.
High output current capacity for robust signal drive. Compact PDIP package for easy PCB mounting. Suitable for industrial, laboratory, audio, and general electronics use. Through Hole mount style for secure assembly.
Explore additional Texas Instruments Operational Amplifiers and other semiconductor components at EnvMart. Find reliable, precision electronics components tailored to industrial and laboratory requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The LM324N/NOPB has a gain bandwidth product of 1 MHz, making it suitable for various amplification applications.
This model supports a supply voltage range from 3 V to 32 V, providing flexibility for different power supply configurations.
It features four independent operational amplifiers in a single package, allowing for multiple signal processing tasks.
The dimensions of this unit are 19.69 mm in length, 6.6 mm in width, and 5.08 mm in height, facilitating easy integration into PCBs.
The maximum output current capability is 40 mA, enabling it to drive moderately low-impedance loads effectively.
The typical input offset voltage for this model is 9 mV, which is beneficial for precision applications.
It operates within a temperature range of 0°C to 70°C, suitable for standard industrial environments.
This unit is packaged in a 14-pin PDIP format, which supports standard through-hole PCB assembly.
The input bias current is 500 nA and the input offset current is 150 nA, which contribute to its precision in analog signal processing.
It is commonly applied in industrial automation, laboratory instrumentation, audio systems, and general electronics.
The country of origin for this operational amplifier is India.
This model supports through-hole mounting, ensuring a secure assembly for prototyping and production applications.
