Texas Instruments Operational Amplifier 1 MHz 14-Pin CDIP 32V LM124J/PB
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Texas Instruments |
| Height | 5.08mm |
| Length | 19.94mm |
| Model | LM124J/PB |
| Width | 7.19mm |
| Mount Type | Through Hole |
| Series | LM124 |
| Output Current | 20mA |
| Maximum Operating Temperature | 125°C |
| Package Type | CDIP |
| Minimum Operating Temperature | -55°C |
| Number Of Channels | 4 |
| Pin Count | 14 |
| Maximum Supply Voltage | 32V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 1MHz |
| Input Bias Current | 50 nA |
| Vos - Input Offset Voltage | 2 mV |
| Input Offset Current | 10 nA |
Key Features
- Features four operational amplifier channels integrated in a single package.
- Gain bandwidth product of 1 MHz suitable for moderate frequency applications.
- Operates with supply voltages ranging from 3V to 32V for flexible power configurations.
- Designed for through-hole mounting in a 14-pin ceramic dual in-line package.
- Supports operating temperatures from -55°C up to 125°C for wide environmental use.
- Low input offset voltage of 2 mV and input bias current of 50 nA ensuring signal accuracy.
- Maximum output current of 20 mA ideal for driving moderate loads.
- A reliable component for electronic, industrial control, and instrumentation applications.
Product Description
Texas Instruments LM124J/PB is a high-performance operational amplifier designed for a variety of electronic applications. This model features four independent amplifier channels packed into a 14-pin Ceramic Dual In-line Package (CDIP), making it well suited for through-hole mounting and integration into traditional circuit board designs.
With a gain bandwidth product of 1 MHz, the LM124J/PB supports moderate speed amplification tasks commonly required in control systems, signal conditioning, and industrial instrumentation. The device supports a wide supply voltage range from 3V to 32V, enabling flexible powering options and ensuring reliable operation across different circuit requirements.
The operational amplifier boasts a low input offset voltage of 2 mV and an input bias current of only 50 nA, contributing to precise signal amplification and minimal distortion. Its maximum output current is 20 mA, suitable for driving medium loads without additional buffering. Designed to operate in harsh environments, it withstands temperatures from -55°C up to 125°C.
The physical dimensions measure 19.94 mm in length, 7.19 mm in width, and 5.08 mm in height, making it suitable for compact setups while maintaining ease of handling during assembly.
Four independent operational amplifier channels enhance multi-signal processing on a single chip. 1 MHz gain bandwidth product balances speed and accuracy for complex signal applications. Wide operating temperature range ensures functionality in industrial and automotive environments.
Through-hole ceramic DIP package ensures strong physical mounting and durability. Low input offset voltage and current provide high accuracy in analog signal processing. High supply voltage tolerance offers design flexibility across various applications.
Ideal for use in electronic instrumentation, industrial control, and automated systems.
This Texas Instruments LM124J/PB Operational Amplifier is a dependable choice for engineers requiring stable analog signal amplification in demanding environments. Explore our Electronics & Electricals catalog for more advanced semiconductor and amplifier products tailored to industrial and laboratory needs at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 1 MHz, making it suitable for moderate frequency applications.
It operates with supply voltages ranging from 3V to 32V, allowing for flexible power configurations in various applications.
This model features four independent operational amplifier channels integrated into a single package.
The physical dimensions are 19.94 mm in length, 7.19 mm in width, and 5.08 mm in height.
The maximum output current is 20 mA, which is suitable for driving moderate loads.
It has a low input offset voltage of 2 mV, contributing to signal accuracy.
The input bias current is 50 nA, which helps ensure precise signal amplification.
This model can operate within a temperature range of -55°C to 125°C, making it suitable for various environmental conditions.
It is designed for through-hole mounting in a 14-pin ceramic dual in-line package (CDIP).
It is ideal for use in electronic instrumentation, industrial control, and automated systems.
The input offset current is 10 nA, which is beneficial for maintaining signal integrity.
The country of origin for this operational amplifier is Thailand.
