Omron Screw DIN Track Power Relay 24V DC Coil 25A Switching Current G7Z-3A1B-02Z-R DC24
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Omron |
| Height | 62mm |
| Length | 45mm |
| Model | G7Z-3A1B-02Z-R DC24 |
| Width | 92.2mm |
| Mount Type | Screw, DIN Track |
| Contact Material | Silver Alloy |
| Series | G7Z |
| Maximum Operating Temperature | 60°C |
| Contact Configuration | 3PST-NO, SPST-NC |
| Minimum Operating Temperature | -25°C |
| Switching Current | 25A |
| Terminal type | Screw |
| Contact Resistance | 400mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 156Ω |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 125V dc |
| Switching AC Voltage | 480V |
| Coil Power | 3.7W |
Key Features
- Operates with a 24V DC coil voltage and coil power of 3.7W for reduced power consumption.
- Supports a switching current of up to 25A suitable for heavy-load applications.
- Silver alloy contacts provide low contact resistance of 400mΩ ensuring efficient conductivity.
- Switching capability includes 480V AC and 125V DC voltages for versatile circuit use.
- Mounts easily via screw terminals or standard DIN rail assemblies for flexible installation.
- Designed to work reliably in temperatures ranging from -25°C to 60°C.
- Contact configuration includes 3PST-NO and SPST-NC for diverse control logic requirements.
Product Description
Omron G7Z-3A1B-02Z-R DC24 is a precision screw and DIN track power relay engineered for industrial automation and electrical control systems. It features a 24V DC coil that consumes 3.7W of power, reducing energy draw while ensuring consistent and reliable actuation.
This relay supports a switching current capacity of 25 amperes, accommodating heavy-load circuits in industrial panels and distribution racks. The silver alloy contacts deliver a low contact resistance of 400 milliohms, enhancing electrical efficiency and durability.
It is designed to switch AC voltages up to 480V and DC voltages up to 125V, providing flexibility in managing both AC and DC power circuits. The coil resistance of 156 ohms ensures predictable coil current at the rated voltage for stable operation.
The relay includes multiple contact arrangements, such as three-pole single-throw normally open (3PST-NO) and single-pole single-throw normally closed (SPST-NC) configurations, supporting various control logic designs.
Mounting is versatile with screw terminals for secure conductor clamping and compatibility with DIN rail assemblies, making integration into control cabinets and electrical panels straightforward and reliable.
Designed to perform steadily within a wide operating temperature range from -25°C to 60°C, this relay suits diverse industrial environments including automation panels, electrical distribution systems, and control applications that require dependable power switching.
Operates on a 24V DC coil with low 3.7W power consumption. Handles switching currents up to 25A for robust load control. Silver alloy contacts ensure low resistance and high conductivity. Switching voltage ratings of 480V AC and 125V DC accommodate varied applications.
Mounts flexibly using screw terminals or DIN rail configurations. Wide operating temperature range suitable for harsh environments. Multiple contact arrangements support complex control requirements.
This Omron power relay is ideal for industrial automation, electrical load switching, motor control panels, and retrofit installations in control cabinets. It is a reliable component for critical power switching in manufacturing, HVAC, and commercial electrical systems.
Explore more Power Relays and automation control components with EnvMart for advanced industrial and electrical solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay operates with a coil voltage of 24V DC.
It supports a maximum switching current of 25A, making it suitable for heavy-load applications.
The relay can switch AC voltages up to 480V and DC voltages up to 125V.
It features a contact configuration of 3PST-NO and SPST-NC, allowing for diverse control logic designs.
The contact resistance is 400 milliohms, which ensures efficient conductivity.
The coil power consumption is 3.7W, which helps in reducing energy draw.
It operates reliably within a temperature range of -25°C to 60°C.
It can be mounted using screw terminals or standard DIN rail assemblies for flexible installation.
The coil resistance is 156 ohms, ensuring predictable coil current at the rated voltage.
The contacts are made of silver alloy, which provides low contact resistance and high conductivity.
It complies with RoHS standards, ensuring environmental safety and compliance.
This relay is suitable for industrial automation, electrical load switching, and motor control panels.
