Nexperia 4 2-Input NOR Logic Gate 74HC02D,653, 14-Pin SO, CMOS, 2V-6V, 29ns Propagation Delay 74HC02D,653

Nexperia 74HC02D,653 is a 4 2-input NOR logic gate device housed in a 14-pin SO package, delivering reliable and low-power CMOS logic operations. It features a maximum propagation delay time of 29 nanoseconds and supports operating voltages from 2 V to 6 V, making it compatible with mixed 5 V and 3.3 V applications. This device is suitable for surface mounting on printed circuit boards and provides enhanced signal integrity for complex logic circuit layouts.

The NOR function provided by the 74HC02D,653 is essential in digital control, glue logic, PCB miniaturization, and routing simplification applications. Each gate has clamp diodes on inputs allowing the use of current limiting resistors to interface inputs to voltages beyond VCC. The product operates reliably within a wide temperature range from -40°C to 125°C, suitable for demanding industrial environments.

Key industrial applications include use in cell phones, computing platforms, STB LCD TVs, and industrial controllers, benefiting from low power consumption and robust CMOS input logic levels. The device has single-ended outputs with maximum output currents of 5.2 mA low level and -5.2 mA high level, supporting clean logic switching.

This Nexperia logic gate is RoHS compliant, ensuring environmentally friendly design, and is designed to reduce time to market for complex designs with its mature CMOS technology. Its compact form factor and overvoltage tolerant options make it an excellent choice for embedded system engineers and electronics manufacturers.

The device includes four independent 2-input NOR gates suitable for a variety of digital logic tasks. It supports a broad supply voltage range from 2 V to 6 V for flexible integration. Compact 14-pin SO package supports surface mount applications on PCBs.

Inputs with clamp diodes enable interfacing to voltages in excess of VCC safely. The logic gate operates across -40°C to 125°C, meeting industrial temperature requirements. The device is optimized for low power consumption and high signal integrity in complex layouts.

Typical uses include digital logic in cell phones, TVs, computing, and industrial controllers. Manufactured under series 74HC2D CMOS technology, ensuring mature and reliable performance. Explore more semiconductor logic gates and components in the Electronics & Electricals > Semiconductor > Logic Gate category on EnvMart for advanced digital circuit solutions.
