Texas Instruments Operational Amplifier 200 MHz, 5-Pin 5.5V SOT-23 OPA356AIDBVT
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.15mm |
| Length | 2.9mm |
| Model | OPA356AIDBVT |
| Width | 1.6mm |
| Mount Type | Surface |
| Series | OPA356 |
| Output Current | 100mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Standards/Approvals | RoHS |
| Pin Count | 5 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 200MHz |
| Input Bias Current | ±50 pA |
| Vos - Input Offset Voltage | ±15 mV |
| Slew Rate | 360V/μs |
Key Features
- Operates with supply voltage range from 3V to 5.5V.
- Single-channel amplifier suitable for high-speed applications.
- Low input bias current of ±50 pA ensures precision performance.
- Input offset voltage at ±15 mV and slew rate of 360 V/μs.
- Automotive standard AEC-Q100 certified for reliability.
- Compact dimensions of 2.9mm length, 1.6mm width, and 1.15mm height.
- Maximum operating temperature up to 125°C allows for harsh environments.
- Output current capability of 100mA.
Product Description
Texas Instruments OPA356AIDBVT is a high-performance operational amplifier built for precise, high-speed signal processing in a compact 5-pin SOT-23 surface mount package. It provides a 200 MHz gain bandwidth product making it well-suited for demanding applications in industrial automation, instrumentation, and automotive electronics.
This device operates reliably over a supply voltage range of 3V to 5.5V and meets automotive-grade AEC-Q100 standards, ensuring robustness under elevated temperatures up to 125°C. The low input bias current of ±50 pA and input offset voltage of ±15 mV contribute to its accuracy, while a fast slew rate of 360 V/μs enables rapid signal transitions.
The single channel operational amplifier delivers output current up to 100 mA, suitable for driving loads in audio, sensor conditioning, and signal conditioning tasks. Its compact 2.9mm by 1.6mm by 1.15mm footprint supports space-constrained PCB designs, making it an ideal choice for densely populated electronic assemblies.
Common industrial uses include use in signal amplification in test and measurement equipment, motor control systems, and communication devices requiring precise analog front-end circuits.
Operates on a supply range from 3V to 5.5V for flexibility. Provides high gain bandwidth product of 200 MHz for high-speed signals. Features low input bias current to minimize signal errors. Complies with automotive AEC-Q100 for enhanced reliability.
Compact SOT-23 package for surface mounting and space savings. Wide temperature operation from -40°C to 125°C. Fast slew rate supports dynamic analog signals. Output current up to 100 mA for various load drives.
The OPA356AIDBVT represents a reliable, efficient solution for electronics engineers designing high-frequency operational amplifier circuits, combining precision, speed, and automotive-grade quality. Explore related Operational Amplifiers and high-performance analog semiconductor components at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The OPA356AIDBVT has a gain bandwidth product of 200 MHz, making it suitable for high-speed signal processing applications.
It operates within a supply voltage range of 3V to 5.5V, providing flexibility for various applications.
The maximum operating temperature for this model is 125°C, allowing it to function in harsh environments.
This operational amplifier can deliver an output current of up to 100 mA, suitable for driving various loads.
The dimensions of this model are 2.9 mm in length, 1.6 mm in width, and 1.15 mm in height, making it compact for space-constrained designs.
It features a low input bias current of ±50 pA, which helps minimize signal errors in precision applications.
The input offset voltage for the OPA356AIDBVT is ±15 mV, contributing to its accuracy in signal processing.
The slew rate of this operational amplifier is 360 V/μs, enabling rapid signal transitions.
This model complies with the automotive standard AEC-Q100, ensuring reliability in automotive applications.
It comes in a compact SOT-23 package, which is designed for surface mounting.
The minimum operating temperature for this operational amplifier is -40°C, making it suitable for a wide range of environments.
This operational amplifier is a single-channel device, designed for high-speed applications.
