Nisshinbo Micro Devices Operational Amplifier 1.3 MHz 15V Dual Channel 8-Pin SSOP NJM3414AV-TE2
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nisshinbo Micro Devices |
| Model | NJM3414AV-TE2 |
| Mount Type | Surface |
| Series | NJM3414A |
| Maximum Operating Temperature | 85°C |
| Package Type | SSOP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Minimum Supply Voltage | 15V |
| GBP - Gain Bandwidth Product | 1.3MHz |
| Input Bias Current | 500 nA |
| Vos - Input Offset Voltage | 5 mV |
| Slew Rate | 1V/μs |
| Input Offset Current | 100 nA |
Key Features
- Offers a bipolar technology dual operational amplifier capable of driving 70mA output current.
- Gain bandwidth product rated at 1.3 MHz for precise signal amplification.
- Operates within a temperature range of -40°C to 85°C ensuring reliability in industrial environments.
- Has low input offset voltage of 5 mV and low input bias current of 500 nA.
- Designed with an 8-pin SSOP surface mount package for compact PCB integration.
- Features a slew rate of 1 V/μs for moderate-speed signal conditioning.
- Compliant with RoHS standards ensuring environmental safety.
- Dual channel design allows for versatile analog signal processing.
Product Description
Nisshinbo Micro Devices NJM3414AV-TE2 is a dual operational amplifier designed for high gain and high output current applications. It features a gain bandwidth product of 1.3 MHz and is housed in a compact 8-pin SSOP surface mount package. The device supports a supply voltage of 15 V and operates reliably within a temperature range from -40°C up to 85°C, making it suitable for a broad range of industrial and electronic equipment.
This integrated circuit employs bipolar technology, offering low input offset voltage of 5 mV and input bias current of 500 nA, which ensures precise signal amplification. The operational amplifier provides a slew rate of 1 V/μs and is capable of delivering an output current up to 70 mA, facilitating driving moderate loads efficiently.
The NJM3414AV-TE2 dual channel architecture allows versatile use in various applications, including audio amplification, instrumentation, and signal conditioning in laboratory or industrial environments.
Dual channel operational amplifier with high gain bandwidth. Bipolar technology for strong output current and voltage swing. Low input offset voltage and bias current for accuracy. Surface mount SSOP 8-pin package for compact PCB design.
Wide operating temperature range from -40°C to 85°C. Slew rate suitable for moderate speed signal processing. RoHS compliant ensuring reduced environmental impact. Capable of driving a 70 mA output load. Ideal for industrial, laboratory, audio, and measurement systems.
Package contents include the NJM3414AV-TE2 dual operational amplifier device. For further design support, 3D models and schematics are available through DesignSpark software. This operational amplifier is well-suited for professionals involved in industrial electronics, manufacturing instrumentation, and laboratory instrumentation requiring reliable analog signal amplification.
Explore more products in the Operational Amplifier category to find compatible components and complementary devices that meet your design specifications at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is rated at 1.3 MHz, allowing for precise signal amplification.
It is capable of driving an output current of up to 70 mA, making it suitable for moderate load applications.
This model operates reliably within a temperature range of -40°C to 85°C.
It is housed in an 8-pin SSOP surface mount package, which is designed for compact PCB integration.
The input offset voltage is 5 mV, and the input bias current is 500 nA, ensuring accurate signal amplification.
The slew rate of the NJM3414AV-TE2 is 1 V/μs, suitable for moderate-speed signal conditioning.
Yes, it is compliant with RoHS standards, ensuring reduced environmental impact.
This model features a dual channel design, allowing versatile analog signal processing.
The minimum supply voltage required for the NJM3414AV-TE2 is 15 V.
It is suitable for applications including audio amplification, instrumentation, and signal conditioning in industrial environments.
The input offset current for this model is specified at 100 nA.
The operational amplifier is manufactured in India.
