Texas Instruments Octal D Type Flip Flop Logic IC 74HCT TTL Input LSTTL Output 23 MHz Clock Frequency 20-Pin PDIP SN74HCT273N

Texas Instruments SN74HCT273N is an Octal D Type Flip Flop integrated circuit belonging to the 74HCT logic family, designed to handle TTL input signals and provide LSTTL output. The device comes in a 20-pin PDIP package, which supports through-hole mounting methods commonly used in electronic assemblies.

This flip flop supports a maximum clock frequency of 23 MHz, facilitating high-speed operations in digital circuits. It incorporates two D-type flip-flop elements that trigger on the positive edge of the clock signal, enabling versatile and synchronized data storage and transfer.

The supply voltage range is designed from a minimum of 4.5V to a maximum of 5.5V, ensuring stable operation under typical 5V digital circuit standards. The maximum propagation delay time under a given load capacitance is approximately 36 nanoseconds, which helps maintain timing integrity in complex digital systems.

Operating temperature ranges from -40°C to 85°C, making the SN74HCT273N suitable for a wide range of industrial and commercial applications, including embedded systems, communication equipment, and control systems. Its LSTTL output characteristics make it compatible with modern digital logic levels.

The device complies with industry standards and is a reliable choice for sequencing and buffering digital signals. Its length of 26.92mm and height of 5.8mm fit standard circuit board layouts and placement requirements.

The IC offers a high clock frequency of 23 MHz for rapid switching. It supports through-hole mounting in a 20-pin PDIP package. The supply voltage range is 4.5V to 5.5V, aligning with digital circuit norms. Two D-type flip flop elements are included for multi-bit data handling.

Positive edge triggering allows precise timing control. The operating temperature range is from -40°C to 85°C for industrial robustness. Maximum propagation delay is 36 nanoseconds, aiding timing accuracy. Length and height dimensions are 26.92mm and 5.8mm respectively.

This Texas Instruments logic IC is ideal for industrial electronics, embedded digital systems, and telecommunications equipment requiring stable and fast flip flop functionality. Explore our catalog for additional semiconductor components suited for diverse industrial and laboratory applications.
