TE Connectivity Micro-MaTch Series Vertical Surface PCB Header 10 Contact 1.27 mm Pitch 2 Row Shrouded 8-338728-0
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 100V |
| Brand | TE Connectivity |
| Orientation | Vertical |
| Current | 1A |
| Mount Type | Surface |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | Micro-MaTch |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Tin |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board |
| Mating Pin Length | 5.2mm |
Key Features
- Designed with a vertical orientation and two rows for compact PCB integration.
- Shrouded connector housing made from durable polyamide for protection.
- Features copper alloy contacts plated with tin ensuring low resistance.
- Supports up to 1 Amp current and 100V operating voltage.
- Designed for surface mount solder termination on PCBs of 1.6 mm thickness.
- Operates reliably between -40°C and 105°C temperature range.
- Mating pin length is 5.2 mm to ensure stable electrical contact.
- Ideal for industrial electronics requiring secure and compact PCB headers.
Product Description
TE Connectivity 8-338728-0 Micro-MaTch Series Vertical Surface PCB Header is a high-quality connector designed for board-to-board applications. Featuring 10 male contacts arranged in two rows with a 1.27 mm pitch, this shrouded header ensures reliable mating and mechanical protection.
The housing is made from robust polyamide material, providing durability in industrial environments. Copper alloy contacts with tin plating offer low resistance and excellent conductivity, suitable for a nominal current of 1 Amp and voltage rating of 100V.
This surface mount header is designed to fit PCBs with a standard thickness of 1.6 mm, making it versatile for various printed circuit board assemblies. Temperature tolerance ranges from -40°C to 105°C ensuring stable performance in a wide array of operating conditions.
The mating pins extend 5.2 mm providing secure connections during assembly and operation. The shrouded design protects the contacts from accidental damage and short circuits, enhancing product reliability in industrial, electronics manufacturing, and assembly line environments.
Designed with a vertical two-row configuration and 10 contacts to maximize compactness and connectivity. Polyamide housing provides chemical resistance and mechanical stability. Copper alloy contacts plated with tin offer superior conductivity and corrosion resistance.
Supports 1A current and 100V voltage rating suitable for low power applications. Operates over a broad temperature range from -40°C to 105°C. Shrouded design prevents shorting and improves durability. Ideal for industrial, electronics, and commercial PCB connections requiring robust headers.
This product is ideal for designers and engineers requiring reliable, space-saving solutions for PCB interconnects in laboratories, manufacturing, and automation industries. Explore TE Connectivity products for advanced connectivity at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current of 1 Amp.
It has a voltage rating of 100V.
The contacts are arranged with a pitch size of 1.27 mm.
It operates reliably within a temperature range of -40°C to 105°C.
The housing is made from polyamide, providing durability and chemical resistance.
This model features 10 male contacts arranged in two rows.
It uses a solder termination type for mounting on PCBs.
The mating pin length is 5.2 mm, ensuring stable electrical contact.
Yes, it is designed for surface mount solder termination on PCBs of 1.6 mm thickness.
It is classified as a board-to-board connector system.
The contacts are made from copper alloy and are plated with tin for low resistance.
This unit is ideal for industrial electronics requiring secure and compact PCB headers.
