Panasonic DP-101 Series Pressure Sensor NPN/PNP Output Gauge Reading -1 bar to 10 bar DP-102

Panasonic DP-102 pressure sensor from the DP-101 Series is a highly reliable digital pressure sensor featuring a gauge reading range from -1 bar minimum to 10 bar maximum. Designed for use with non-corrosive gas media, this sensor offers NPN or PNP output options, providing flexibility for industrial automation, process control, and instrumentation applications.

The sensor features a dual digital display allowing simultaneous visibility of current pressure and set threshold values. Its wide viewing angle and increased clarity enhance monitoring and diagnostics in industrial and laboratory environments. An efficient circuit redesign reduces power consumption by 14%, with additional savings when display brightness is lowered or shut off.

Encased in durable polybutylene terephthalate housing, the DP-102 can be panel-mounted and offers an IP40 rating, protecting against solid objects larger than 1 mm and moderate environmental exposure. The unit operates reliably across temperatures from -10°C to 50°C, suitable for varied industrial settings. Wiring is provided via wire lead terminals, facilitating straightforward integration into control systems.

This sensor complies with EMC Directive standards, ensuring minimal electromagnetic interference and adherence to industry safety regulations. Its response time of 5000 ms makes it ideal for applications where steady, accurate pressure measurement is critical.

Applications include industrial automation, HVAC systems, pneumatic controls, manufacturing process monitoring, and laboratory instrumentation, where precise pressure management and reliability are essential.

Equipped with dual display for enhanced visibility and wide viewing angle. Selectable voltage or current output provides versatile interface options. Low power consumption design improves energy efficiency by up to 14%. Operating temperature range from -10°C to 50°C suitable for diverse environments.

Robust polybutylene terephthalate housing with panel mount and IP40 rating. Response time of 5000 ms suitable for steady state pressure monitoring. Wired lead terminal type for secure connectivity. Complies with EMC Directive standards ensuring electromagnetic compatibility.

Compact design with full range performance and easy installation. Explore Panasonic Pressure Sensors and other advanced sensor technology at EnvMart for reliable industrial and laboratory instrumentation solutions.
