Infineon PVG612 Series Solid State Relay 2.4 A Load Surface Mount 60 V AC/DC

Free Delivery in India | Lowest Global Shipping Charges

Infineon PVG612 Series Solid State Relay 2.4 A Load Surface Mount 60 V AC/DC

Name: Infineon PVG612 Series Solid State Relay 2.4 A Load Surface Mount 60 V AC/DC
Brand: Infineon
SKU: 253045
Price: 8.74 USD
Availability: InStock



Category Solid State Relay Brand Infineon Condition New

Specifications

Country of Origin	Philippines
Brand	Infineon
Height	3.4mm
Length	8.6mm
Model	PVG612
Width	6.5mm
Mount Type	Surface
Output type	Current/Voltage
Series	PVG612
Maximum Operating Temperature	85°C
Contact Configuration	SPST
Capacitance	130pF
Minimum Operating Temperature	-40°C
Terminal type	PCB Terminal
Maximum Load Current	2.4A
Standards/Approvals	RoHS
Maximum Load Voltage	60V ac/dc
Minimum Load Voltage	0V

Key Features

This solid state relay is a single pole, single throw (SPST) configuration suitable for general purpose switching.
It features a transistor output using HEXFET power MOSFET technology for low noise and bounce-free operation.
The relay operates reliably over a temperature range of -40°C to 85°C.
It has a compact surface-mount form factor with dimensions of 8.6 mm length, 6.5 mm width, and 3.4 mm height.
The device provides high isolation voltage of 4000 VRMS between input and output, ensuring signal integrity.
Capacitance is low at 130 pF, suitable for signal conditioning applications.
It has PCB terminals and is RoHS compliant, making it environmentally friendly.
The product originates from the Philippines and is ideal for industrial and electronic automation use cases.

Product Description

Infineon PVG612S-TPBF solid state relay is a high-performance surface mount device offering a maximum load current of 2.4 A and a maximum load voltage of 60 V AC/DC. It utilizes Infineon's HEXFET power MOSFET technology integrated with a photovoltaic generator providing superior switching characteristics and low noise operation.

This relay adopts a single pole single throw (SPST) normally open contact configuration perfect for replacing electromechanical relays in industrial, laboratory, construction, automation, and manufacturing equipment for analogue signal switching.

Engineered for durability and reliability, the relay operates efficiently over a wide temperature range of -40°C to 85°C, making it adaptable for harsh environments. Its surface mount type and compact dimensions (8.6 mm x 6.5 mm x 3.4 mm) facilitate easy PCB integration and space saving on circuit boards.

With a high input-to-output isolation voltage of 4000 VRMS and capacitance of only 130 pF, it preserves signal integrity in sensitive electronic applications. The relay features PCB terminal type connections and adheres to RoHS standards, guaranteeing environmental safety and compliance.

This solid state relay supports current/voltage output type tailored for precise control applications. It ensures bounce-free switching, enhancing the operational reliability of control systems. The low off-state resistance and high dv/dt rating improve performance in noise-sensitive circuits.

Its robust construction includes transistor output (FET & MOSFET) technology for extended service life. Ideal for use in electrical automation, industrial control panels, and signal conditioning systems.

Originating from the Philippines, this Infineon relay model PVG612S-TPBF is a dependable component for advanced industrial electronics where compact size and reliable performance are critical. For additional product exploration, please browse related Solid State Relays on EnvMart.
