onsemi Rail to Rail Current Sensing Amplifier Single 6-Pin SC-70 NCS213RSQT2G
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | onsemi |
| Height | 1mm |
| Length | 2.2mm |
| Model | NCS213RSQT2G |
| Mount Type | Surface |
| Output type | Rail to Rail |
| Series | NCS213 |
| Maximum Operating Temperature | 125°C |
| Package Type | SC-70 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Pin Count | 6 |
| Maximum Supply Voltage | 26V |
| Minimum Supply Voltage | 2.2V |
| Supply Current | 80μA |
| GBP - Gain Bandwidth Product | 90kHz |
| CMRR - Common Mode Rejection Ratio | 100dB |
Key Features
- The device operates over a wide supply voltage range from 2.2 V to 26 V.
- It features a low supply current of 80 μA suitable for low power applications.
- The amplifier offers a fixed gain of 50 V/V enabling precise current sensing across low-value shunt resistors.
- The device maintains accuracy with a common mode rejection ratio (CMRR) of 100 dB.
- Operates over a temperature range of -40°C to 125°C for industrial applications.
- Compact SC-70 surface mount package measuring 2.2 mm length and 1 mm height.
- Rail to rail output facilitates use in high voltage and automotive environments.
- The device is manufactured in Malaysia and belongs to the NCS213 series.
Product Description
onsemi NCS213RSQT2G Rail to Rail Current Sensing Amplifier is a high-performance semiconductor amplifier designed to sense current by measuring voltage across shunt resistors with exceptional accuracy. The amplifier features a fixed gain of 50 V/V and a low offset zero-drift architecture that enables measurement of low voltage drops across the shunt as low as 10 mV full-scale.
The single channel amplifier operates on a single supply voltage ranging from 2.2 V up to 26 V, drawing a minimal supply current of only 80 μA, making it well suited for power-sensitive applications. It delivers a rail-to-rail output, providing compatibility with high voltage systems and automotive use cases.
This device is housed in a compact 6-pin SC-70 surface mount package with dimensions of 2.2 mm length and 1 mm height, facilitating easy integration into compact PCB designs. It maintains a robust operating temperature range from -40°C to 125°C, ensuring reliable performance in industrial and automotive environments.
Notable features include a high common mode rejection ratio (CMRR) of 100 dB and established series pedigree under NCS213. The amplifier supports high side current sensing with low valued current sense resistors, improving power efficiency in applications such as automotive battery management, industrial controls, and power supply current monitoring.
The device supports wide common mode voltage range from -0.3 V to 26 V independent of supply voltage. Low power consumption suits battery operated and low power systems. High common mode rejection facilitates precise sensing in noisy environments.
Small package size enables dense PCB layouts. Rail-to-rail output enhances dynamic range for signal processing. Broad operating temperature range suits harsh industrial conditions. Manufactured in Malaysia ensuring international quality standards.
This Current Sensing Amplifier is ideal for engineers and designers working in industrial, automotive, and power electronics fields. It integrates seamlessly into applications requiring accurate current monitoring to optimize power consumption and system safety.
Explore more semiconductor amplifiers in the onsemi series available at EnvMart for versatile design and manufacturing needs.
