onsemi Rail to Rail Current Sensing Amplifier Single 6-Pin SC-70 NCS199A3RSQT2G
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | onsemi |
| Height | 1mm |
| Length | 2.2mm |
| Model | NCS199A3RSQT2G |
| Mount Type | Surface |
| Output type | Rail to Rail |
| Series | NCS199 |
| Maximum Operating Temperature | 125°C |
| Package Type | SC-70 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Pin Count | 6 |
| Maximum Supply Voltage | 26V |
| Minimum Supply Voltage | 2.2V |
| Supply Current | 60μA |
| GBP - Gain Bandwidth Product | 40kHz |
| CMRR - Common Mode Rejection Ratio | 100dB |
| Low Offset Drift | 0.5 μV/°C |
Key Features
- The device operates with a supply voltage range from 2.2V to 26V.
- Common Mode Rejection Ratio (CMRR) is 100 dB, ensuring high accuracy.
- The package type is compact SC-70 with 6 pins and surface mount design.
- The operating temperature range spans from -40°C to 125°C.
- Supply current is low at 60μA for power-efficient operation.
- The gain bandwidth product (GBP) is 40 kHz for dynamic response.
- The output is rail to rail, compatible with a wide range of systems.
- Low offset drift of 0.5 μV/°C maintains stability over temperature variations.
Product Description
onsemi NCS199A3RSQT2G is a high precision rail to rail current sensing amplifier featuring a single channel in a compact 6-pin SC-70 package. It is engineered to provide accurate voltage output reflecting the voltage drop across current sense resistors with a wide common-mode voltage range from -0.3 V to 26 V.
This device operates on a single power supply ranging from 2.2 V to 26 V, drawing a minimal supply current of 60μA, making it highly efficient for power monitoring and control applications. It exhibits a low offset voltage of ±150 μV max and a low offset drift of 0.5 μV/°C, ensuring precision even under varying temperatures. The common mode rejection ratio (CMRR) of 100 dB ensures noise and interference are effectively minimized.
With a gain bandwidth product (GBP) of 40 kHz, it caters to a variety of fast response applications including power adapters, feedback control loops, and telecom DC-DC modules. The rail to rail output facilitates integration with varying logic levels and power supplies.
Its small package size (2.2 mm length, 1 mm height) is ideal for compact PCB layouts in industrial, commercial, and laboratory environments. The extended operating temperature range from -40°C to 125°C supports reliable operation in harsh conditions.
Typical applications include high side current sensing for power monitoring, fast chargers for smartphones, wireless charging systems, high-end computing servers, and e-cigarettes. The device is made in Malaysia and adheres to relevant semiconductor standards without automotive certification.
Operates from 2.2 V to 26 V supply voltage. Low supply current of 60μA reduces power consumption. High CMRR of 100 dB ensures stable measurements. Compact surface mount SC-70 package with 6 pins. Wide operating temperature range from -40°C to 125°C.
Rail to rail output for signal compatibility. Low offset voltage and offset drift for accuracy. Compact dimension suitable for dense PCB layouts. Designed for high-side current sensing applications. Discover more Current Sensing Amplifiers and semiconductor amplifiers in the Electronics & Electricals section at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a supply voltage range from 2.2V to 26V.
The CMRR is 100 dB, ensuring high accuracy and stability in measurements.
The package dimensions are 2.2 mm in length and 1 mm in height.
The maximum operating temperature is 125°C, allowing for reliable operation in harsh conditions.
It has a low supply current of 60μA, making it efficient for power monitoring applications.
The gain bandwidth product is 40 kHz, suitable for fast response applications.
It features a rail to rail output, which is compatible with a wide range of systems.
The low offset drift is 0.5 μV/°C, which helps maintain accuracy over temperature variations.
The minimum operating temperature is -40°C, supporting its use in extreme environments.
This device features a single channel configuration.
It utilizes a surface mount design, suitable for compact PCB layouts.
Typical applications include high side current sensing for power monitoring and fast charging systems.
