MERCURY 14.7456MHz Clock Oscillator ±50 ppm HCMOS TTL 5V 8-Pin PDIP 5H8ET-14.7456
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | MERCURY |
| Height | 5.08mm |
| Length | 12.8mm |
| Model | 5H8ET-14.7456 |
| Width | 12.8mm |
| Mount Type | Through Hole |
| Series | H8 |
| Maximum Operating Temperature | 85°C |
| Output Frequency | 14.7456MHz |
| Package Type | PDIP |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Maximum Supply Voltage | 5V |
| Oscillator Type | Clock |
| Output Level | HCMOS, TTL |
Key Features
- Oscillator operates at 14.7456MHz frequency with high stability.
- Output compatible with HCMOS and TTL logic levels.
- Maximum supply voltage is 5V suitable for a wide range of electronic circuits.
- Compact metal package with 8-pin DIP footprint for easy PCB integration.
- Operating temperature range is from -40°C to 85°C suitable for industrial applications.
- Standard series H8 complying with RoHS environmental standards.
- Pin count of 8 allows easy interface with clock and timing circuits.
- Manufactured in Taiwan, Province of China ensuring quality production.
Product Description
The MERCURY 5H8ET-14.7456 Clock Oscillator is an industry-standard, high-precision clock source engineered for industrial, laboratory, and electronic applications requiring reliable timing signals. Featuring a fundamental frequency of 14.7456MHz with ±50 ppm frequency stability over a wide operating temperature range, this oscillator ensures accurate timing and synchronization.
Its compact 8-pin PDIP metal package supports through-hole mounting, making it ideal for PCB assembly in embedded electronics. The output supports HCMOS and TTL levels, providing compatibility with a wide range of digital logic systems.
The oscillator runs on a maximum supply voltage of 5V and has robust operating temperatures from -40°C up to +85°C, suitable for harsh or industrial environments. Compliance with RoHS standards confirms environmentally conscious manufacturing processes.
Key features include the H8 series reliable construction, precise frequency control, and standardized pin configuration, simplifying design and replacement processes in embedded systems, communications equipment, and control electronics.
Oscillator operates at 14.7456MHz frequency with high stability. Output compatible with HCMOS and TTL logic levels. Maximum supply voltage is 5V suitable for a wide range of electronic circuits. Compact metal package with 8-pin DIP footprint for easy PCB integration.
Operating temperature range is from -40°C to 85°C suitable for industrial applications. Standard series H8 complying with RoHS environmental standards. Pin count of 8 allows easy interface with clock and timing circuits.
Manufactured in Taiwan, Province of China ensuring quality production.
This clock oscillator is widely used in industrial automation, communication devices, instrumentation, and embedded system design. It delivers reliable timing essential for microprocessor clocking, serial communication synchronization, and signal processing applications.
Explore more advanced clock oscillators and timing devices to complement your industrial and electronics projects on EnvMart.
Explore more products in our Crystal Oscillator category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The output frequency of this model is 14.7456MHz, providing a reliable timing signal for various applications.
The maximum supply voltage for this oscillator is 5V, making it suitable for a wide range of electronic circuits.
It supports HCMOS and TTL logic levels, ensuring compatibility with various digital logic systems.
The operating temperature range is from -40°C to 85°C, which is suitable for industrial applications.
This oscillator comes in a compact PDIP package type, which supports through-hole mounting for easy PCB integration.
The oscillator features a pin count of 8, allowing for easy interface with clock and timing circuits.
It is manufactured in Taiwan, ensuring quality production standards.
This model belongs to the H8 series, known for its reliable construction and precise frequency control.
The dimensions are 12.8mm in length and width, with a height of 5.08mm.
It complies with RoHS environmental standards, confirming environmentally conscious manufacturing processes.
This oscillator is widely used in industrial automation, communication devices, instrumentation, and embedded system design.
It is a clock oscillator designed to provide reliable timing signals for various electronic applications.
