Panasonic Film Capacitor 100 nF 16V dc 16V ac Surface Mount ECHU1C104JX5

Panasonic ECHU1C104JX5 film capacitor is a high-quality surface mount passive component designed for electronic applications requiring a capacitance of 100 nF and rated for 16V dc and 16V ac voltages.

Manufactured using stacked metallised PPS film with a mould-less construction, this capacitor offers a durable and reliable solution for circuits exposed to high temperatures up to 125°C.

The compact form factor at 3.2 mm length, 2.5 mm width, and 2.1 mm height allows efficient PCB layout and improved production efficiency with surface mount technology (SMT) compatibility.

Featuring a low Equivalent Series Resistance (ESR) and recommended for reflow soldering processes, it ensures excellent performance for filtering, timing, oscillation, and audio applications in industrial, commercial, and consumer electronics.

Constructed with metallised PPS film for durability and stable electrical properties. Surface mount type designed for reflow soldering processes. Compact design enabling space-saving electronic assemblies. Rated for 16V dc and 16V ac operation with 125°C maximum temperature rating.

Suitable for time constant, filtering, resonance, and audio circuit applications. RoHS compliant ensuring environmentally friendly manufacturing and usage. Dimensions: 3.2 x 2.5 x 2.1 mm (LxWxH) for accurate PCB integration.

This film capacitor is ideal for designers and engineers working on electronics projects in automotive, industrial controls, consumer electronics, and other demanding environments requiring robust passive components.
