TE Connectivity Micro MATE-N-LOK Series Right Angle Surface PCB Header 6 Contacts 3 mm Pitch 2 Row Shrouded 3-794627-6

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity Micro MATE-N-LOK Series Right Angle Surface PCB Header 6 Contacts 3 mm Pitch 2 Row Shrouded 3-794627-6

Name: TE Connectivity Micro MATE-N-LOK Series Right Angle Surface PCB Header 6 Contacts 3 mm Pitch 2 Row Shrouded 3-794627-6
Brand: TE Connectivity
SKU: 217908
Price: 3.6 USD
Availability: InStock



Category PCB Connectors & Wire Housings Brand TE Connectivity Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	TE Connectivity
Orientation	Right Angle
Current	5A
Mount Type	Surface
Housing Material	Nylon
Contact Material	Brass
Series	Micro MATE-N-LOK
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-65°C
Number of Rows	2
Pitch	3mm
Contact Plating	Tin
Number of Contacts	6
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	3.18mm

Key Features

The connector features a right angle orientation suitable for surface PCB mounting.
Constructed with durable nylon housing and brass contacts plated with tin for reliable conductivity.
Supports a current rating of 5A and operates at voltages up to 250V.
Complete with positive locking tabs and polarization to prevent mis-mating.
Designed for solder termination and includes tail pins of 3.18 mm length.
Operates reliably in temperatures ranging from -65°C to 105°C.
Ideal for wire-to-board connection in industrial and consumer electronics applications.
Durable nylon housing provides mechanical protection and electrical insulation.

Product Description

TE Connectivity 3-794627-6 Micro MATE-N-LOK Series Right Angle Surface PCB Header is a high-reliability connector with a 3 mm pitch, 6 male contacts arranged in 2 rows, and shrouded nylon housing. It ensures secure and precise connections with polarization to avoid mis-mating and positive lock tabs to secure cable connectors. The right angle orientation supports surface mounting on PCBs, making it ideal for compact designs.

The header's brass contacts are plated with tin, providing good electrical conductivity and corrosion resistance. Tail pins extend to 3.18 mm for solder termination, ensuring a strong mechanical and electrical bond to the PCB. The connector operates safely at 250 V and can handle currents up to 5 A, making it suitable for a wide range of electronic and industrial equipment.

Designed for harsh environments, it withstands operating temperatures from -65°C to 105°C. This connector system supports IR reflow soldering processes and includes boardlocks or solder retention to enhance PCB stability during assembly.

The Micro MATE-N-LOK series finds extensive applications in household appliances, lighting, factory automation, data storage, and security systems. Its low-profile designs suit industries such as LED lighting and other constrained-spatial applications.

The connector features a right angle design optimized for space-constrained PCBs. Durable nylon housing provides mechanical protection and electrical insulation. Polarization and positive locking tabs increase connection reliability and safety.

Suitable for industrial, commercial, and consumer electronics uses. Supports standard SMT and through-hole soldering techniques.

This product is a new TE Connectivity component that complies with industry standards, offering robust performance in demanding environments. Explore more from the Micro MATE-N-LOK connector range at EnvMart for seamless integration in your electronic projects.
