TE Connectivity Micro MATE-N-LOK Series Right Angle Surface PCB Header, 6 Contacts, 3 mm Pitch, 2 Rows, Shrouded 3-794627-6

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity Micro MATE-N-LOK Series Right Angle Surface PCB Header, 6 Contacts, 3 mm Pitch, 2 Rows, Shrouded 3-794627-6

Name: TE Connectivity Micro MATE-N-LOK Series Right Angle Surface PCB Header, 6 Contacts, 3 mm Pitch, 2 Rows, Shrouded 3-794627-6
Brand: TE Connectivity
SKU: 217907
Price: 3.6 USD
Availability: InStock



Category PCB Connectors & Wire Housings Brand TE Connectivity Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	TE Connectivity
Orientation	Right Angle
Current	5A
Mount Type	Surface
Housing Material	Nylon
Contact Material	Brass
Series	Micro MATE-N-LOK
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-65°C
Number of Rows	2
Pitch	3mm
Contact Plating	Tin
Number of Contacts	6
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	3.18mm

Key Features

Constructed with durable nylon housing for high reliability.
Shrouded design prevents mis-mating and ensures secure connections.
Contacts are brass with tin plating supporting up to 5A current capacity.
Suitable for industrial and consumer electronics applications requiring 250V rating.
Designed for surface mounting with solder termination and 3.18 mm tail pin length.
Operates reliably within temperature range from -65°C to 105°C.
Features polarization and positive lock tabs for secure cable connector mating.
Ideal for use in household appliances, lighting, factory automation, and data storage equipment.

Product Description

TE Connectivity 3-794627-6 Micro MATE-N-LOK Series right angle surface PCB header features 6 male contacts arranged in 2 rows with a 3 mm pitch, designed for wire-to-board connections. The connector housing is made of high-quality nylon, providing durability and insulation, and is shrouded to prevent mis-mating.

The brass contacts with tin plating ensure optimal electrical conductivity and a current rating of 5A with a voltage rating of 250V. This component includes solder termination with a tail pin length of 3.18 mm, suitable for surface mount PCB applications.

Operating temperature ranges from -65°C to 105°C, making it suitable for demanding industrial environments. The design incorporates features such as polarization and positive lock tabs to secure mating connectors firmly and prevent accidental disconnections. The boardlocks and solder tail retention features ensure a stable installation on PCBs.

This Micro MATE-N-LOK header series is compatible with IR reflow soldering processes and is ideal for a wide range of applications including household appliances, lighting solutions, factory automation systems, data storage, and security systems. The low profile and robust construction also make it suitable for LED lighting configurations.

Durable nylon housing prevents electrical faults and enhances longevity. Polarization and locking tabs provide secure and error-free mating. Brass contacts with tin plating ensure consistent electrical performance. Designed for surface mount with solder termination and retention features.

Wide operating temperature range accommodates various industrial settings. 5A current and 250V voltage ratings support moderate power applications. Shrouded connector design improves safety and user handling. Broad applicability in industrial, residential, and commercial electronics.
