Cosel DC/DC Converter SUTS102405, 5V DC Output, 2A, 24V DC Max Input, 8.58W Power, PCB Mount, 1900 kHz Switching Frequency
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters Cosel SUTS DC/DC Converter, 5V dc/ 2 A, 24V dc Inp |
| Brand | Cosel |
| Efficiency | 85% |
| Length | 45.2mm |
| Model | SUTS102405 |
| Depth | 29.3mm |
| Gross Weight | 14g |
| Width | 29.3mm |
| Mount Type | PCB |
| Series | SUTS |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Ripple and Noise | 200mV Pk-Pk |
| Maximum Output Power | 8.58W |
| Maximum Input Voltage | 24V dc |
| Maximum Switching Frequency | 1900kHz |
| Standards/Approvals | CE, UL 60950-1, TUV, EN 60950-1, cULus, cUL |
| Minimum Input Voltage | 18V |
| Number of Pins | 7 |
| Output Voltage 1 | 5V dc |
| Output Current 1 | 2A |
| Isolation Voltage | 500V ac |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- Supports input voltage range from 18V to 24V DC.
- Provides a regulated 5V DC output with a maximum current of 2A.
- Maximum output power of 8.58 watts with 85% efficiency for energy saving.
- Compact DIP package with PCB mount type suitable for embedded systems.
- Operating temperature range from -40°C to 85°C for reliable performance in harsh environments.
- Features a high switching frequency of 1900 kHz for reduced size and noise.
- Built-in isolation voltage of 500V AC ensuring safety and signal separation.
- Overcurrent protection and remote ON/OFF functionality for enhanced reliability.
Product Description
Cosel SUTS102405 DC/DC Converter is a high-performance, isolated converter designed for power supply applications requiring a regulated 5V DC output at up to 2A current. It accepts an input voltage ranging from 18V to 24V DC and delivers reliable power output of 8.58 watts with up to 85% efficiency. The converter is housed in a DIP package, optimized for PCB mounting in compact industrial or electronic designs.
Designed with robust built-in protection circuitry, this DC/DC converter incorporates overcurrent protection and remote ON/OFF control for flexible operation. With a wide operating temperature range from -40°C to 85°C, it is suitable for demanding industrial, instrumentation, and embedded systems environments.
The unit operates at a high switching frequency of 1900 kHz, enabling a compact footprint and reduced electromagnetic interference. An isolation voltage of 500V AC guarantees safe electrical separation between input and output, ensuring compliance with industry safety standards including CE, UL 60950-1, TUV, EN 60950-1, cULus.
This converter is especially suited for use in industrial automation, communication equipment, laboratory electronics, and power management systems where reliable, compact, and efficient DC power conversion is required.
Supports input voltage range from 18V to 24V DC. Provides regulated 5V DC output at 2A current. Compact DIP package with PCB mounting capability. Built-in overcurrent protection and remote ON/OFF feature. High switching frequency of 1900 kHz reduces size and noise.
Wide operating temperature range from -40°C to 85°C. Isolation voltage rated at 500V AC. Efficiency of 85% ensures energy saving operation. Complies with CE, UL 60950-1, TUV, EN 60950-1, cULus safety standards.
Cosel products are trusted globally for their high quality and reliability in power conversion. Explore the Electronics & Electricals category on EnvMart for more advanced DC/DC Converters from Cosel and other leading brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports an input voltage range from 18V to 24V DC.
The maximum output power of this converter is 8.58 watts.
It provides a regulated output of 5V DC with a maximum current of 2A.
This converter has an efficiency rating of 85%.
The dimensions are 45.2mm in length, 29.3mm in width, and 29.3mm in depth.
The maximum switching frequency is 1900 kHz.
It features an isolation voltage rated at 500V AC.
The operating temperature range is from -40°C to 85°C.
This model is designed for PCB mounting.
Yes, it includes built-in overcurrent protection and remote ON/OFF functionality.
It complies with CE, UL 60950-1, TUV, EN 60950-1, and cULus safety standards.
This converter has one output.
