Preci-Dip 852 Series Straight Surface Pin Header, 10 Contacts, 1.27 mm Pitch, 2 Row, Unshrouded, Brass 852-80-010-30-001191

Preci-Dip 852-80-010-30-001191 PCB Pin Header is a high-quality electronic connector suited for precise applications requiring a straight surface mount configuration. Featuring 10 male brass contacts with tin plating, this component offers reliable electrical connections with a 1.27 mm pitch and 2-row arrangement, providing compact and efficient integration on printed circuit boards.

The housing is composed of fibreglass reinforced polyethylene terephthalate, ensuring robust mechanical strength and thermal stability across a wide operating temperature range from -55°C to 125°C. Designed for solder termination, it facilitates secure mounting and long-term durability in various industrial, laboratory, and manufacturing environments.

This pin header supports current ratings of up to 1A and voltages up to 150V, making it suitable for low power applications. It is unshrouded with a straight orientation to allow easy mating with complementary connectors or wire assemblies.

Manufactured in Switzerland under stringent quality controls, this Preci-Dip connector complies with UL 94V-0 flammability standard, ensuring safety in demanding applications. The compact footprint and precise pitch offer excellent performance in electronics manufacturing, prototyping, and repair scenarios.

Constructed with brass contacts plated in tin for effective conductivity. Housing made of fibreglass reinforced polyethylene terephthalate for durability. Capable of handling 1A current and operating voltages up to 150V.

Designed for surface mount applications with solder termination. Operates reliably across temperatures from -55°C to 125°C. Male contact gender and straight orientation for secure mating. Complies with UL 94V-0 flame retardant standards.

Manufactured in Switzerland ensuring quality and precision.

This pin header is widely used in electronics and electrical manufacturing sectors, including industrial instrumentation, telecommunications equipment, control panels, and prototype assemblies. Its sturdy construction and precise specifications make it an ideal choice for reliable signal and power connections. Browse related PCB Pin Headers and connectors in the EnvMart catalog for compatible components and accessories.
