Preci-Dip 852 Series Straight Surface Pin Header 10 Contacts 1.27 mm Pitch 2 Row Unshrouded 852-80-010-30-001191
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 1A |
| Mount Type | Surface |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | 852 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Tin |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
Key Features
- Features 10 male brass contacts for reliable electrical connections.
- Unshrouded design enhances accessibility and assembly ease.
- Constructed with fibreglass reinforced polyethylene terephthalate housing for durability.
- Surface mount type with straight orientation and 2 rows of contacts provides compact PCB integration.
- Supports operating voltage up to 150V and current rating of 1A.
- Operates reliably between -55°C and 125°C temperature range.
- Tin plated contact finish ensures corrosion resistance and longevity.
- Solder termination type suitable for robust mounting on circuit boards.
Product Description
Preci-Dip 852-80-010-30-001191 Straight Surface Pin Header is a high-precision PCB connector designed for industrial and electronic applications. The housing is made of fibreglass reinforced polyethylene terephthalate, providing excellent mechanical strength and durability under operational stresses.
The connector supports a maximum operating voltage of 150V and current rating of 1 ampere, making it suitable for low power electronic circuits. Its operating temperature range spans from -55°C to 125°C, ensuring reliable performance in harsh environmental conditions. The contacts are manufactured from brass and finished with tin plating to prevent corrosion and maintain electrical integrity over time.
This unshrouded pin header design allows easy access for assembly and inspection, ideal for applications requiring frequent mating cycles or visual confirmation of connections. The solder termination type ensures secure attachment to the PCB, enhancing mechanical stability during operation.
Features 10 male brass contacts for reliable electrical connections. Unshrouded design enhances accessibility and assembly ease. Constructed with fibreglass reinforced polyethylene terephthalate housing for durability. Surface mount type with straight orientation and 2 rows of contacts provides compact PCB integration.
Supports operating voltage up to 150V and current rating of 1A. Operates reliably between -55°C and 125°C temperature range. Tin plated contact finish ensures corrosion resistance and longevity. Solder termination type suitable for robust mounting on circuit boards.
This pin header is widely used in electronic manufacturing, industrial controls, communications equipment, and other applications requiring sturdy and precise PCB connectors. Its compliance with UL 94V-0 standards supports flame retardance and safety in electrical installations. Originating from Switzerland, this connector exemplifies Swiss precision engineering and quality assurance.
Explore more from Preci-Dip and related products in the PCB Pin Header category at EnvMart for reliable and high-quality electronic component sourcing.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating voltage of this pin header is 150V.
This model has a current rating of 1A.
It operates reliably within a temperature range of -55°C to 125°C.
This pin header features 10 male contacts.
The pitch size of the contacts is 1.27 mm.
The housing is constructed from fibreglass reinforced polyethylene terephthalate.
This connector uses a solder termination type for secure mounting on circuit boards.
The orientation of this pin header is straight.
This model is unshrouded, which enhances accessibility and assembly ease.
The contacts are made from brass and are tin plated to prevent corrosion.
This connector originates from Switzerland, reflecting Swiss precision engineering.
It is widely used in electronic manufacturing, industrial controls, and communications equipment.
