Preci-Dip 803 Series Right Angle Surface PCB Socket 6-Contact 2 Row 2.54 mm Pitch Solder 803-87-006-30-002101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Right Angle |
| Current | 12A |
| Mount Type | Surface |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Beryllium Copper Alloy |
| Series | 803 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold Flash |
| Number of Contacts | 6 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Features a right angle orientation suitable for surface mount applications.
- Equipped with 6 female contacts arranged in 2 rows with a 2.54 mm pitch.
- Constructed with black glass filled polyester housing for durability and insulation.
- Contact material is beryllium copper alloy with gold flash plating ensuring excellent conductivity.
- Rated for 12 Amperes current and 150 Volts operating voltage.
- Suitable for operating temperatures from -55°C up to 125°C.
- Designed for board-to-board connector systems with solder termination.
- Manufactured in Switzerland with high quality standards.
Product Description
Preci-Dip 803-87-006-30-002101 is a right angle surface PCB socket designed for electronic assemblies requiring robust and reliable board-to-board connections. This PCB socket accommodates 6 female contacts in 2 rows with a 2.54 mm pitch and is suitable for surface mounting on printed circuit boards.
The socket features black glass filled polyester housing, combining mechanical strength and electrical insulation to protect the contacts and the PCB. Its contacts are made of beryllium copper alloy, renowned for excellent electrical conductivity and mechanical resilience, and are gold flash plated for corrosion resistance and superior contact reliability.
Electrical specifications include a current rating of 12A and maximum voltage rating of 150V, ensuring suitability for a range of power and signal applications. The connector supports operation across a wide temperature range from -55°C to 125°C, making it appropriate for harsh industrial and electronic environments.
The solder termination ensures a secure mechanical and electrical connection to the PCB, while its right angle orientation allows for efficient use of PCB space and cable routing. This model belongs to the 803 series by Preci-Dip, a trusted name in high-precision connector solutions.
Right angle orientation for surface mount PCB applications. 6 female contacts arranged in 2 rows with 2.54 mm pitch. Durable black glass filled polyester housing. Beryllium copper alloy contact with gold flash plating for reliability.
Rated for 12A current and 150V voltage. Operating temperature range from -55°C to 125°C. Solder termination for secure PCB mounting. Manufactured in Switzerland adhering to high-quality standards.
This PCB socket is ideal for use in electronics manufacturing, automotive, industrial control systems, and any application requiring dependable board-to-board interconnection. Preci-Dip's 803 series ensures precision, performance, and durability in demanding environments.
Explore more high-quality PCB Sockets and connectors in the Electronics & Electricals category at EnvMart, your reliable partner for industrial-grade electronic components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket is rated for a current of 12 Amperes.
The maximum voltage rating for this socket is 150 Volts.
It features a housing made of black glass filled polyester and contacts made of beryllium copper alloy with gold flash plating.
The socket has a pitch of 2.54 mm and accommodates 6 female contacts arranged in 2 rows.
This model can operate within a temperature range from -55°C to 125°C.
It uses solder termination for secure mounting on the PCB.
The socket is designed with a right angle orientation suitable for surface mount applications.
This socket is manufactured in Switzerland, adhering to high-quality standards.
It supports a board-to-board connector system.
This model features a total of 6 female contacts.
It is suitable for use in electronics manufacturing, automotive, and industrial control systems.
This socket belongs to the 803 series by Preci-Dip.
