Preci-Dip 5 Way Preci-Dip Straight Through Hole 1.27 mm Pitch SIL Socket 100 V ac, 150 V dc, Solder, 1A 851-87-005-10-001101

Preci-Dip 851-87-005-10-001101 5 Way SIL Socket is a high-precision Swiss-made SIL socket designed for electronic applications requiring reliable, low-profile PCB connectors operating at 100 V AC and 150 V DC with a 1A current rating. This straight pitch socket features a 1.27 mm contact pitch and through hole mounting style, suitable for robust solder connection on printed circuit boards.

The contacts of the socket are constructed from beryllium copper alloy and brass, featuring gold and tin plating to provide excellent electrical conductivity and resistance to corrosion and wear. Its housing is made from fibreglass reinforced polycyclohexylenedimethylene terephthalate, offering increased mechanical durability and heat resistance up to 125°C.

This SIL socket has compact physical dimensions of 6.76 mm length, 2.2 mm width, and 4.1 mm depth, making it ideal for space-constrained industrial and electronic circuit designs. It is rated for minimum operating temperature down to -55°C, which supports usage in varied environmental conditions typical in industrial, laboratory, and manufacturing electronics assembly.

The product adheres to UL 94V-0 flammability standards and is suitable for use in applications such as power and signal connectors within electronic components assemblies. It is well-suited for the electronics manufacturing industry, including PCB assembly, test equipment, and other precision electronic instrumentation environments.

Features five contacts made of beryllium copper alloy and brass for durability. Rated for 100 V AC and 150 V DC voltage applications. Supports a current rating of 1 ampere. Contact plating includes gold and tin to ensure excellent conductivity and corrosion resistance.

Constructed with a fibreglass reinforced polycyclohexylenedimethylene terephthalate housing material for mechanical strength. Designed for through hole mounting with solder termination type. Operates reliably in a temperature range of -55°C to 125°C.

Compact dimensions with length 6.76 mm, width 2.2 mm, and depth 4.1 mm. Manufactured in Switzerland ensuring quality standards. No specific approvals or certifications are indicated for this product.

Explore this Preci-Dip SIL Socket and other precision electronic connectors in the EnvMart Electronics & Electricals category to find components suited to your industrial, laboratory, and manufacturing needs.
