Preci-Dip 4 Way Preci-Dip Straight Through Hole 2.54 mm Pitch SIL Socket 150V dc, Solder, 3A 801-87-004-10-012101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 4 Way Preci-Dip Straight Through Hole 2.54 mm Pitch SIL Socket 150V dc, Solder, 3A 801-87-004-10-012101

Name: Preci-Dip 4 Way Preci-Dip Straight Through Hole 2.54 mm Pitch SIL Socket 150V dc, Solder, 3A 801-87-004-10-012101
Brand: Preci-Dip
SKU: 127279
Price: 0.85 USD
Availability: InStock



Category SIL Socket Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	150V dc
Brand	Preci-Dip
Orientation	Straight
Current	3A
Length	10.16mm
Depth	4.2mm
Width	2.54mm
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polycyclohexylenedimethylene Terephthalate
Contact Material	Beryllium Copper Alloy, Brass
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Pitch	2.54mm
Contact Plating	Gold, Tin
Number of Contacts	4

Key Features

Constructed with beryllium copper alloy and brass contact materials for durability.
Contacts plated with gold and tin to ensure excellent conductivity and corrosion resistance.
Designed for through hole mounting with solder termination.
Rated for 150V DC voltage and 3A current capacity.
Compact dimensions with 10.16 mm length and 2.54 mm width enable dense PCB layouts.
Housing made from fibreglass reinforced polycyclohexylenedimethylene terephthalate for thermal and mechanical stability.
Operating temperature range from -55°C to 125°C suitable for various environments.
Standard pitch of 2.54 mm compatible with common IC sockets and headers.

Product Description

Preci-Dip 801-87-004-10-012101 is a 4 Way SIL Socket designed for electronic component interfacing with a precise 2.54 mm pitch and straight through hole mounting style. This socket is well-suited for industrial, laboratory, electronics manufacturing, and prototyping applications where reliable and compact interconnections are required.

The contacts are fabricated from a beryllium copper alloy combined with brass, providing excellent mechanical strength and electrical conductivity. Contact surfaces are plated with gold and tin to enhance corrosion resistance and maintain signal integrity over time. The socket housing is constructed of fibreglass reinforced polycyclohexylenedimethylene terephthalate, known for its thermal stability and insulation properties.

The component is rated for direct current operation up to 150 volts at 3 amperes, with an operational temperature range from -55°C to 125°C, enabling use in various demanding electronic environments. The 10.16 mm length and 2.54 mm width dimensions facilitate installation on standard printed circuit boards with typical hole configurations.

This Preci-Dip socket supports solder termination with through-hole mounting technique, commonly employed in robust electronics assemblies. The connector aligns with UL 94V-0 flammability standards for safe use in electrical products.

Durable contact materials ensure long-term performance and reliability. Precision pitch and dimensions optimize PCB layout compatibility. Stable housing material withstands thermal and mechanical stress. Wide operating temperature range broadens application scope.

Suitable for electronic design, testing, and manufacturing environments. High-quality Swiss manufacturing guarantees connector precision.

Ideal for electronics and electrical engineering sectors requiring dependable IC socket connections. Explore more products and technical resources in the SIL Sockets category at EnvMart.
