Preci-Dip 8 Way Right Angle Through Hole 2.54 mm Pitch SIL Socket 100 V AC, 150 V DC, Solder 399-87-108-10-003101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 8 Way Right Angle Through Hole 2.54 mm Pitch SIL Socket 100 V AC, 150 V DC, Solder 399-87-108-10-003101

Name: Preci-Dip 8 Way Right Angle Through Hole 2.54 mm Pitch SIL Socket 100 V AC, 150 V DC, Solder 399-87-108-10-003101
Brand: Preci-Dip
SKU: 127224
Price: 1.54 USD
Availability: InStock



Category SIL Socket Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	100, 150V ac
Brand	Preci-Dip
Orientation	Right Angle
Current	3A
Length	20.32mm
Depth	2.54mm
Width	2.95mm
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polycyclohexylenedimethylene Terephthalate
Contact Material	Brass, Beryllium Copper Alloy
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Pitch	2.54mm
Contact Plating	Gold, Tin
Number of Contacts	8

Key Features

This SIL socket has 8 contacts suitable for precision electronic connection.
Contacts are made from brass and beryllium copper alloy, plated with gold and tin for enhanced conductivity.
Pitch between contacts is 2.54 mm, ideal for standard IC connections.
Socket housing is made from fibreglass reinforced polycyclohexylenedimethylene terephthalate, providing mechanical stability and durability.
Rated for 100 V AC and 150 V DC operation with maximum operating temperature of 125°C.
Designed for through hole mounting with a socket length of 20.32 mm and depth of 2.54 mm.
Solder termination type ensures secure and reliable PCB connections.

Product Description

Preci-Dip model 399-87-108-10-003101 is a specialized 8 Way SIL Socket designed for right angle through hole installation with 2.54 mm pitch contacts. It operates reliably at 100 V AC and 150 V DC voltages with a current capacity of 3A, making it suitable for use in various industrial and electronic applications.

The socket features 8 precision contacts fabricated from brass and beryllium copper alloy, meticulously plated with gold and tin to ensure excellent electrical performance and corrosion resistance. The housing material is fibreglass reinforced polycyclohexylenedimethylene terephthalate, offering robust mechanical properties and resistance to high operating temperatures, rated up to 125°C.

This through hole mounted socket shows a compact design with a length of 20.32 mm, depth of 2.54 mm, and width of 2.95 mm, making it ideal for high-density PCB layouts in electronic manufacturing, control systems, and instrumentation.

The termination type is solder, ensuring secure electrical and mechanical connection to printed circuit boards. The right angle orientation facilitates flexible design and mounting options on PCBs where vertical space is limited.

These sockets are widely used in electronics assembly, industrial control panels, and precision instrumentation where reliable, removable IC connections are needed. Their durability and electrical specifications meet demanding industrial and laboratory standards.

This SIL socket is built for high reliability and precision electronic connections. Gold and tin contact plating improve signal integrity and corrosion resistance. Fibreglass reinforced housing ensures mechanical durability and thermal stability.

Right angle through-hole mounting supports compact PCB designs. Rated for industrial voltage and temperature ranges, ensuring broad applicability. Suitable for industrial, laboratory, manufacturing, and electronic component assembly use cases.
