Preci-Dip 2 Way Straight Through Hole 2.54 mm Pitch SIL Socket 100 V AC, 150 V DC, Solder Termination 310-87-102-01-640101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 2 Way Straight Through Hole 2.54 mm Pitch SIL Socket 100 V AC, 150 V DC, Solder Termination 310-87-102-01-640101

Name: Preci-Dip 2 Way Straight Through Hole 2.54 mm Pitch SIL Socket 100 V AC, 150 V DC, Solder Termination 310-87-102-01-640101
Brand: Preci-Dip
SKU: 127282
Price: 0.39 USD
Availability: InStock



Category SIL Socket Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	100, 150V ac
Brand	Preci-Dip
Orientation	Straight
Current	3A
Length	5.08mm
Depth	4.2mm
Width	2.54mm
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polycyclohexylenedimethylene Terephthalate
Contact Material	Brass, Beryllium Copper Alloy
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Pitch	2.54mm
Contact Plating	Tin, Gold
Number of Contacts	2

Key Features

The socket features a straight through hole mount style suitable for printed circuit boards.
Contacts are made of brass and beryllium copper alloy providing good conductivity and resilience.
Contact surfaces are plated with tin and gold ensuring reliable solderability and corrosion resistance.
The housing is made from fibreglass reinforced polycyclohexylenedimethylene terephthalate for durability and high temperature tolerance.
Rated operating temperature range spans from -55°C to 125°C for a wide variety of applications.
The socket pins have a diameter of 0.47 mm and length of 3.2 mm, compatible with Preci-Dip pins.
The pitch between contacts is precisely 2.54 mm to match industry-standard spacing.
Termination is by solder tails suitable for reliable PCB mounting.

Product Description

Preci-Dip 310-87-102-01-640101 2 Way SIL Socket is a premium quality, straight through hole connector designed for reliable electronic connections on printed circuit boards. Rated for 100 V AC and 150 V DC operation, it supports a current of up to 3A, making it ideal for low to medium power electronic modules.

The connector features a 2.54 mm pitch between contacts and uses robust brass and beryllium copper alloy contacts for excellent conductivity and mechanical strength. The contacts are plated with tin for solderability and flash gold plating on the beryllium copper spring clips to enhance contact reliability and corrosion resistance.

This SIL socket uses a fibreglass reinforced polycyclohexylenedimethylene terephthalate housing that withstands harsh operating environments, supporting temperatures from -55°C up to 125°C. The straight pin orientation and solder termination style ensure firm mounting and electrical continuity.

The pin diameter measures 0.47 mm with a pin length of 3.2 mm appropriate for standard Preci-Dip pins, providing compatibility and ease of replacement or assembly. This Swiss-manufactured socket is intended for industrial, electronics manufacturing, laboratory instrumentation, telecommunications, and other commercial applications requiring standard, reliable connector interfaces.

The socket's design enables efficient PCB mounting and excellent mechanical stability. Materials selected provide resilience to temperature extremes and operational stress. Compatible with standard 2.54 mm pitch DIP integrated circuits and modules.

Manufactured with strict quality controls in Switzerland for consistent performance. Suitable for electronics prototyping, production, and repair tasks. Explore more SIL Sockets in the Electronics & Electricals section at EnvMart to find complementary connectors and components for your electronic assembly needs.
