Preci-Dip 803 Series Straight PCB Socket 22-Contact 2 Row 2.54 mm Pitch Solder 803-87-022-10-001101

Preci-Dip 803-87-022-10-001101 is a high-quality straight PCB socket designed for electronic and industrial board-to-board connector applications. Featuring 22 contacts arranged in 2 rows with a 2.54 mm pitch, this socket ensures secure solder termination and robust electrical connections for printed circuit boards.

The housing is crafted from black glass filled polyester, providing excellent mechanical strength and resistance to environmental factors. Contacts made of beryllium copper alloy are plated with a gold flash to deliver superior conductivity and corrosion resistance, ensuring durable performance in demanding conditions.

This connector supports a maximum voltage of 150V and can carry currents up to 12A, making it suitable for various electronic circuits requiring reliable power and signal transmission. Its operational temperature range from -55°C to 125°C allows for use in harsh industrial and laboratory environments.

The 803 Series sockets comply with UL 94V-0 flammability standards, providing added safety in electronic assemblies. The straight orientation and female contact gender design facilitate easy integration into standard PCB layouts, supporting both through-hole and surface mount device (SMD) mounting techniques for flexibility in manufacturing processes.

Manufactured in Switzerland, these sockets combine precision engineering with premium materials to deliver consistent and reliable connectivity solutions. The 2.54 mm pitch and low profile design optimize space utilization on PCBs, making the 803 Series suitable for compact and high-density electronic assemblies.

Black glass filled polyester housing ensures durability and mechanical stability. Beryllium copper alloy contacts with gold flash plating for excellent conductivity. Voltage rating of 150V and current rating of 12A cater to demanding applications.

Wide operational temperature range from -55°C to 125°C for reliable performance. Complies with UL 94V-0 standards enhancing safety in electronic designs. Supports both through-hole and SMD mounting for versatile assembly options.

Low profile straight header design reduces PCB space requirements. Female contact gender provides a secure and compatible connection. Manufactured in Switzerland ensuring high quality and precision. 2.54 mm pitch suitable for standard PCB socket configurations.

Preci-Dip 803 Series sockets are ideal for industrial, laboratory, electronic manufacturing, and commercial electronic component assembly applications where precision and reliability are paramount. Explore EnvMart's extensive selection of PCB Sockets and connectors to meet your technical and industrial needs.
