Hirose A3C Series Straight Through Hole Pin Header 8 Contacts 2 mm Pitch 2 Row Unshrouded A3C-8P-2DSA(30)

Hirose A3C-8P-2DSA(30) straight through hole pin header is a high-density miniature connector developed for wire-to-board applications. Featuring 8 male contacts arranged in 2 straight rows with a 2 mm pitch, it is designed to provide stable and reliable electrical connections.

The connector's housing is made from durable polyamide material, capable of withstanding operating temperatures ranging from -55°C to 85°C. Brass contacts with gold plating ensure minimal contact resistance and high corrosion resistance, suitable for intensive industrial and commercial electronic assembly.

This pin header has a current rating of 1A and voltage rating of 200V, matching various low-power electronic devices and control systems. The tail pins measure 2.6 mm in length to facilitate through-hole solder mounting on printed circuit boards, while the mating pins are 3.5 mm long for secure mating connections.

The A3C series is known for its flexibility, available in DIP, SMT, and crimping variations. Its miniature form factor allows for high-density mounting, optimized by the 2 mm pitch grid arrangement. This connector can be stacked for board-to-board applications with 6 mm or 5.1 mm spacing, improving modularity and space efficiency in compact electronic designs.

The product conforms to RoHS standards ensuring environmentally friendly usage. Manufactured in Japan, it is suitable for use in electronics manufacturing, telecommunications, instrumentation, control systems, and various industrial equipment requiring compact and reliable PCB connectors.

The connector is designed for wire-to-board applications with through-hole mount type. Constructed with brass contact material and gold plating for reliable conductivity. Housing is made of polyamide, providing durability and high temperature resistance.

Operates reliably between -55°C and 85°C temperature range. Supports a maximum current rating of 1A and voltage rating of 200V. Tail pin length measures 2.6 mm, and mating pin length is 3.5 mm. The connector is miniature in size, enabling high density mounting in a 2mm pitch grid.

Variation available includes DIP type, SMT, and crimping options. Designed for stacking with spacing of 6mm or 5.1mm between boards depending on type used. Explore the wide range of Hirose electronic components and PCB headers available at EnvMart for your industrial and manufacturing needs.
