Preci-Dip 803 Series Straight PCB Socket 8-Contact 2 Row 2.54 mm Pitch 12A 150V 803-87-008-10-001101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 803 Series Straight PCB Socket 8-Contact 2 Row 2.54 mm Pitch 12A 150V 803-87-008-10-001101

Name: Preci-Dip 803 Series Straight PCB Socket 8-Contact 2 Row 2.54 mm Pitch 12A 150V 803-87-008-10-001101
Brand: Preci-Dip
SKU: 215465
Price: 1.48 USD
Availability: InStock



Category PCB Sockets Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	150V
Brand	Preci-Dip
Orientation	Straight
Current	12A
Mount Type	PCB
Housing Material	Black Glass Filled Polyester
Contact Material	Beryllium Copper Alloy
Series	803
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Board-to-Board
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold Flash
Number of Contacts	8
Contact Gender	Female
Connector System	Board-to-Board

Key Features

The socket supports a current of up to 12A and a voltage rating of 150V.
It has a black glass filled polyester housing for durability.
Contact material is beryllium copper alloy with gold flash plating for reliable conductivity.
The mounting type is PCB with a straight orientation, facilitating easy solder termination.
Operational temperature range is from -55°C to 125°C, suitable for harsh environments.
The connector system is designed for board-to-board connection.
It has female contact gender, suitable for mating with appropriate male pins.
Manufactured in Switzerland ensuring high quality standards.

Product Description

Preci-Dip 803-87-008-10-001101 is a high-quality straight PCB socket designed for reliable board-to-board connections in electronic assemblies. It features 8 female contacts arranged in 2 rows with a standard 2.54 mm pitch, allowing for secure and precise interfacing.

The connector supports a current capacity of 12A and a voltage rating of 150V, making it suitable for various industrial and commercial electronics applications. The housing is made of black glass filled polyester, offering excellent resistance to mechanical and environmental stresses.

Each contact is crafted from beryllium copper alloy and coated with a gold flash plating to ensure optimal electrical conductivity and corrosion resistance. The socket uses solder termination on printed circuit boards, facilitating stable and durable installation.

Designed to operate reliably within a temperature range of -55°C to 125°C, this PCB socket is well-suited for demanding industrial environments such as manufacturing equipment, control systems, telecommunications hardware, and embedded electronics.

The 803 Series by Preci-Dip is known for precision and durability, complying with UL 94V-0 standards for material flammability. The product is manufactured in Switzerland, ensuring stringent quality controls and excellent craftsmanship.

The socket supports 8 contacts over 2 rows with a 2.54 mm pitch. Current capacity of 12A and voltage rating of 150V enable versatile use. Black glass filled polyester housing ensures robustness. Beryllium copper alloy contacts with gold flash plating offer high conductivity.

Designed for solder termination on PCBs with straight orientation. Operates reliably between -55°C and 125°C. Manufactured in Switzerland with high quality standards.

This Preci-Dip PCB socket is ideal for electronics manufacturing, industrial automation, telecommunications, and laboratory instruments. It offers dependable interconnections and long service life for critical PCB applications.
