Preci-Dip 2.54 mm Pitch Vertical 24 Way Surface Turned Pin Open Frame DIL Socket 1A 110-87-624-41-105101

Preci-Dip 110-87-624-41-105101 is a high-quality DIL Socket designed with a 2.54 mm pitch and 24 contacts to support dual inline integrated circuits. This vertical orientation socket is made for surface mounting on printed circuit boards, making it suitable for precision industrial and electronic applications.

The open frame construction allows for efficient reflow soldering processes, including vapour phase soldering, with gull wing terminations that provide robust mechanical strength and facilitate in-circuit testing. The contact materials, comprising beryllium copper alloy and brass, are plated with tin and gold to deliver excellent signal integrity and corrosion resistance.

This socket features a current rating of 1 ampere and supports operating voltages up to 150V DC. It is engineered to withstand a broad temperature range from -55°C to 125°C, meeting the demands of harsh industrial and laboratory environments. With dimensions including a 15.24 mm row width, 30.5 mm length, 17.7 mm width, and 2.8 mm depth, it fits within standard PCB layouts.

The fiberglass reinforced polyethylene terephthalate housing ensures durability and electrical insulation, suitable for manufacturing, electronic equipment assembly, testing stations, and research laboratories.

Standards compliance is indicated by the use of UL 94V-0 rated materials, and the product is manufactured in Switzerland guaranteeing reliable quality. Variants without center bars and with dual center bars are available under different stock numbers for specific assembly needs.

The socket supports a pitch of 2.54 mm, ideal for DIP integrated circuits. Feature vertical orientation with surface mount type for PCB assembly. Constructed with beryllium copper alloy and brass contacts with tin and gold plating for reliable conductivity.

Operates within a voltage of 150V DC and a current rating of 1 ampere. Supports operating temperatures from -55°C to 125°C for industrial applications. The housing is made from fiberglass reinforced polyethylene terephthalate for durability.

Open frame design facilitates easy inspection and reflow soldering with gull wing terminations. Includes 24 contact points arranged with a 15.24 mm row width and 17.7 mm width overall. Compatible with solder termination for through-hole PCB mounting or SMD perpendicular orientation.

Produced in Switzerland ensuring high-quality manufacturing standards.

Explore the full range of DIL Sockets on EnvMart for industrial electronics components and assemblies. This Preci-Dip socket is an excellent choice for reliable and robust PCB connections required in advanced applications.
