Preci-Dip 850 Series Straight Surface Pin Header 5 Contacts 1.27 mm Pitch 1 Row Unshrouded 850-80-005-30-001101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 1A |
| Mount Type | Surface |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | 850 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 1.27mm |
| Contact Plating | Tin |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
Key Features
- Designed with 1 row of unshrouded pins for straightforward board mounting.
- Features brass contact material with tin plating for corrosion resistance.
- Operates between -55°C and 125°C for broad temperature tolerance.
- Supports 1A current at 150V voltage rating.
- Constructed from fibreglass reinforced polyethylene terephthalate housing.
- Surface mount type with solder termination ensures secure attachment.
- Male contact gender suitable for insertion into female connectors.
- Swiss origin guarantees high manufacturing quality standards.
Product Description
Preci-Dip 850-80-005-30-001101 Straight Surface Pin Header delivers precise and durable PCB connections with a 1.27 mm pitch and 5 contacts arranged in a single row. The unshrouded male pins provide efficient connectivity for electronic circuit boards.
This pin header is constructed with high-quality brass contacts plated in tin, ensuring excellent conductivity and corrosion resistance. Its fibreglass reinforced polyethylene terephthalate housing offers mechanical stability and thermal resilience suitable for demanding industrial and electronics manufacturing environments.
The straight orientation and surface mount style support efficient PCB assembly and solder termination, making it ideal for automated manufacturing processes. Operating reliably from -55°C to 125°C, this header accommodates diverse environmental conditions in industrial, laboratory, and commercial electronics applications.
Rated for 1A current and 150V voltage, this connector suits various low-power circuits and control devices. It complies with UL 94V-0 standards for flame retardance but does not possess additional certifications specified.
Manufactured in Switzerland, the 850 series embodies stringent quality controls and Swiss engineering excellence. Designed with 1 row of unshrouded pins for straightforward board mounting. Features brass contact material with tin plating for corrosion resistance.
Operates between -55°C and 125°C for broad temperature tolerance. Supports 1A current at 150V voltage rating. Constructed from fibreglass reinforced polyethylene terephthalate housing. Surface mount type with solder termination ensures secure attachment.
Male contact gender suitable for insertion into female connectors. Swiss origin guarantees high manufacturing quality standards.
This Preci-Dip PCB Pin Header 850 Series is widely used in industrial electronics, custom PCB manufacturing, telecommunications equipment, instrumentation, and automation systems. EnvMart customers can browse our wide selection of connectors for matched complementary parts.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this pin header is 1.27 mm.
This model has 5 contacts arranged in a single row.
It can operate at a maximum temperature of 125°C.
It supports surface mount type with solder termination for secure attachment.
The current rating for this connector is 1A.
The contacts are made of brass and are plated with tin for corrosion resistance.
The minimum operating temperature is -55°C.
It is constructed from fibreglass reinforced polyethylene terephthalate.
This model features unshrouded pins for straightforward board mounting.
The voltage rating is 150V.
It is manufactured in Switzerland, ensuring high manufacturing quality standards.
It is widely used in industrial electronics, custom PCB manufacturing, telecommunications equipment, instrumentation, and automation systems.
