Preci-Dip 800 Series Right Angle Through Hole Pin Header, 9 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 800-80-009-20-001101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | 800 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 9 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
Key Features
- Designed for through-hole mounting with right angle orientation.
- 9 male brass contacts with tin plating for reliable conductivity.
- Pitch spacing of 2.54 mm between pins supporting standard PCB layouts.
- Rated for 3A current and 150V voltage applications.
- Constructed with fibreglass reinforced polyethylene terephthalate housing for durability.
- Operating temperature range from -55°C to 125°C ideal for industrial environments.
- Unshrouded design facilitates easy soldering and visual inspection.
- Complies with UL 94V-0 flammability standard ensuring safety.
Product Description
Preci-Dip 800-80-009-20-001101 is a high-quality right angle through hole pin header designed for printed circuit board (PCB) applications. It features 9 male contacts arranged in a single row with a standard 2.54 mm pitch, making it suitable for versatile electronic component connections.
The housing material is fibreglass reinforced polyethylene terephthalate, providing robustness and resistance to environmental stress. The pins are made from brass and plated with tin, ensuring excellent electrical conductivity and corrosion resistance.
Rated to operate safely within a temperature range of -55°C to 125°C, this connector is ideal for use in industrial, manufacturing, and electronic assembly environments that require reliable performance under varying conditions.
This unshrouded connector supports a current rating of 3 amperes and voltage rating of up to 150 volts. Its through-hole mount type and right angle orientation allow for secure mounting and compact PCB design, facilitating efficient space utilization in electronic assemblies.
Through hole right angle mount ensuring stable mechanical connection. 9 male brass contacts with tin plating for optimized electrical performance. Pitch of 2.54 mm for compatibility with standard industry designs. Fibreglass reinforced polyester housing for enhanced durability.
Wide operating temperature range (-55°C to 125°C) suitable for harsh conditions. Voltage rating up to 150V supporting various electronic applications. Current capacity of 3A for standard power deliveries. Unshrouded design allows easy inspection and maintenance.
Manufactured in Switzerland ensuring high-quality standards.
These connectors are commonly used in electronic manufacturing, automation systems, and industrial equipment where dependable PCB connections are essential. The Preci-Dip 800 Series offers a reliable and durable solution for right angle PCB interconnections.
Explore more high-grade PCB connectors and electronic components at EnvMart to optimize your industrial and manufacturing projects.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a maximum voltage of 150V, making it suitable for various electronic applications.
It has a current rating of 3A, allowing it to handle standard power deliveries in electronic circuits.
The pitch spacing is 2.54 mm, which is compatible with standard PCB layouts.
This pin header features 9 male contacts arranged in a single row.
It operates safely within a temperature range of -55°C to 125°C, suitable for industrial environments.
The housing is constructed from fibreglass reinforced polyethylene terephthalate, providing durability and resistance to environmental stress.
This model uses solder termination, facilitating secure connections on PCBs.
It features an unshrouded design, which allows for easy soldering and visual inspection during assembly.
This connector is manufactured in Switzerland, ensuring adherence to high-quality standards.
It has a right angle orientation, which is beneficial for compact PCB designs and efficient space utilization.
It is commonly used in electronic manufacturing, automation systems, and industrial equipment requiring reliable PCB connections.
The contacts are made from brass and plated with tin, ensuring excellent electrical conductivity and corrosion resistance.
