Preci-Dip 830 Series Right Angle Through Hole Pin Header, 2 Contacts, 2 mm Pitch, 1 Row, Unshrouded 830-80-002-20-001101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 830 Series Right Angle Through Hole Pin Header, 2 Contacts, 2 mm Pitch, 1 Row, Unshrouded 830-80-002-20-001101

Name: Preci-Dip 830 Series Right Angle Through Hole Pin Header, 2 Contacts, 2 mm Pitch, 1 Row, Unshrouded 830-80-002-20-001101
Brand: Preci-Dip
SKU: 215199
Price: 0.54 USD
Availability: InStock



Category PCB Pin Header Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	150V
Brand	Preci-Dip
Orientation	Right Angle
Current	3A
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polymer
Contact Material	Brass
Series	830
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2mm
Contact Plating	Tin
Number of Contacts	2
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded

Key Features

Features a right angle orientation for optimized PCB layout flexibility.
Constructed with brass contacts plated in tin for reliable conductivity.
Housing made from fibreglass reinforced polymer for durability and thermal stability.
Supports a current of up to 3A and voltage rating of 150V.
Designed with a single row and unshrouded configuration for easy soldering.
Minimum operating temperature of -55°C and maximum of 125°C for versatile environments.
Termination type is solder through hole ensuring stable mechanical and electrical connection.
Manufactured in Switzerland adhering to UL 94V-0 flame retardant standards.

Product Description

Preci-Dip 830-80-002-20-001101 is a high quality right angle through hole pin header, part of the 830 Series designed for electronic PCB connector applications. It features 2 male contacts with a 2 mm pitch arranged in a single row, enabling compact and reliable connections in electronic assemblies.

The pin header is constructed with brass contacts plated with tin, providing excellent electrical conductivity and corrosion resistance. The housing is made of fibreglass reinforced polymer, which offers mechanical strength and thermal stability suitable for demanding environments.

Operating within a temperature range of -55°C to 125°C, this unshrouded pin header supports up to 3A current and 150V, making it dependable for various industrial and electronic uses. Its through hole solder termination ensures a robust physical and electrical bond to the PCB.

This component is manufactured in Switzerland under UL 94V-0 flame retardant standard for enhanced safety compliance. It is ideal for use in industrial electronics manufacturing, laboratory instruments, control systems, and other electronic equipment requiring reliable PCB connectors.

Right angle orientation enabling space-saving PCB designs. 2 contacts with 2 mm pitch for precise connection spacing. Robust fibreglass reinforced polymer housing for durability. Brass tin plated contacts for optimal conductivity and longevity.

Through hole solder termination for strong mechanical mounting. Wide operating temperature range from -55°C to 125°C. Rated for 3A current and 150V voltage to support various circuits. Single row, unshrouded design for ease of assembly and inspection.

Manufactured in Switzerland ensuring quality and compliance. Suitable for industrial, laboratory, and commercial electronic applications.

This pin header component is part of the comprehensive Preci-Dip connector range at EnvMart, offering precise and reliable PCB header solutions for professional electronic manufacturing. Browse more connectors and PCB components on EnvMart to find compatible parts to complete your assembly.
