Panasonic Short Hinge Lever Micro Switch, Solder Terminal, 100mA, 250 V AC, 30 V DC, SPCO AVT321261-A

Panasonic AVT321261-A is a subminiature short hinge lever micro switch designed for use in various industrial and commercial electrical applications requiring precise and reliable switching. The solder terminal type facilitates robust electrical connections, ideal for devices where consistent contact and operational longevity are critical.

This micro switch supports a contact current of 100mA and is rated for 250 V AC and 30 V DC operation, making it suitable for low power circuit switching tasks. The SPCO contact configuration provides a single pole changeover function for versatile circuit applications.

The actuator employs a short hinge lever designed to provide high precision and smooth operation with an operating force of just 0.2N, enabling sensitive triggering. The device performs reliably over a wide temperature range from -25°C to 85°C, allowing usage in diverse environments including industrial automation systems, communication devices, vending machines, security systems, and medical equipment.

Constructed with flux-resistant materials and integrally moulded terminals, it guarantees long-lasting durability and resistance to environmental factors. Its design includes common pitch and angle terminal options for straightforward PCB mounting.

The mechanical life expectancy of 500,000 operations ensures longevity and consistent performance in demanding scenarios. Panasonic AVT series switches meet international standards including CSA, RoHS, UR, and VDE certifications, highlighting compliance and safety.

Short hinge lever actuator for precise control. Solder terminals for secure connection. 100mA current capacity at 250 V AC / 30 V DC. SPCO contact configuration functions as single pole change over. Operating force 0.2N for sensitive and reliable actuation.

Wide operating temperature range (-25°C to 85°C). Subminiature size for compact integration. Mechanical durability rated at 500,000 cycles. Flux-resistant construction for enhanced reliability. International standards compliance: CSA, RoHS, UR, VDE.

Ideal for use in industrial control systems, telecommunications, vending machines, security equipment, and medical instrumentation. Panasonic’s AVT321261-A model offers precision, durability, and compact design to meet rigorous industrial requirements.
