onsemi Digital Transistor 50 V NPN + PNP 100 mA Surface Mount SOT-363 (SC-88), 6-Pin Model MUN5311DW1T1G

onsemi MUN5311DW1T1G is a digital transistor featuring a dual resistor configuration integrated with bipolar NPN + PNP transistors. Packaged in a compact SOT-363 (SC-88) 6-pin surface mount package, this device supports maximum collector emitter voltage of 50 V and a continuous collector current rating of 100 mA, making it suitable for a range of electronic switching and amplification applications.

This transistor offers a minimum DC current gain of 35 and a low collector emitter saturation voltage of 0.25 V, enhancing its performance for efficient switching tasks. The maximum power dissipation is 500 mW, which accommodates moderate power applications while maintaining thermal stability up to 150°C operating temperature.

The compact form factor with dimensions 2.2 mm length, 1.35 mm width, and 0.9 mm height supports high-density PCB layouts. It is RoHS compliant and meets automotive standards AEC-Q101, ensuring suitability for automotive and industrial environments requiring robust and reliable components.

These resistor-equipped digital transistors allow direct interfacing with digital circuits without additional bias components, simplifying PCB design and reducing component count. The isolated transistor configuration provides flexibility in circuit design by ensuring minimal interference between device terminals.

Maximum collector emitter voltage: 50 V. Continuous collector current: 100 mA. Power dissipation: 500 mW. DC current gain (minimum): 35. Operating temperature up to 150°C. RoHS and Pb-Free compliant for environmental safety.

Automotive grade AEC-Q101 certification. Compact surface mount SOT-363 (SC-88) 6-pin package. Low collector emitter saturation voltage of 0.25 V. Dual resistors integrated for direct digital driving capability.

This digital transistor is widely used in industrial electronics, automotive controls, and signal processing where compact size, reliability, and ease of digital interfacing are critical. It is ideal for signal amplification, switching, and temperature-sensitive applications in harsh environments.
