STMicroelectronics Thyristor SCR 600 V 16 A Surge Current 314 A TO-220 TYN625RG

STMicroelectronics TYN625RG is a robust thyristor designed as a silicon controlled rectifier (SCR) with a peak reverse voltage rating of 600 V and an average on-state current of 16 A. Featuring a TO-220 package and through-hole mount, this device is engineered for power switching and control in demanding industrial environments.

The TYN625RG supports a surge current rating up to 314 A, allowing it to withstand transient spikes effectively. With a maximum gate trigger current of 40 mA and gate trigger voltage of 1.3 V, it provides reliable turn-on characteristics. Its 3-pin configuration supports straightforward integration on PCBs.

The device operates efficiently over a temperature range from -40°C to 125°C, making it suitable for a range of electronic component applications, including power supply controls, motor drives, and other power switching uses. The peak on-state voltage of 1.6 V and minimal off-state leakage currents contribute to high efficiency during operation.

Although this component carries no specific certifications or automotive standards, it is part of the 25 A SCR series from STMicroelectronics, known for quality and durability in power electronics.

Engineers and designers will find this thyristor advantageous for enhancing performance and reliability of power control applications in industrial automation, HVAC systems, manufacturing equipment, and other commercial settings.

The thyristor features a surge current rating of 314 A to handle peak power requirements. Maximum gate trigger current is 40 mA ensuring sensitive gate activation. It sustains a maximum operating temperature of 125°C, suitable for robust industrial applications.

Comes with a peak on-state voltage of 1.6 V and a repetitive peak off-state current of 5 µA for efficient power control. The device is a 3-pin silicon controlled rectifier designed for high reliability in power switching.

Operational temperature ranges from -40°C to +125°C, supporting diverse environmental conditions. Suitable for general purpose SCR applications in industrial and electronic components sectors. Browse the Electronics & Electricals category for more Semiconductor products, or explore STMicroelectronics components for a comprehensive range of Thyristors and SCRs.
