HARWIN Datamate J-Tek Series Straight Panel PCB Socket, 20-Contact, 2 Row, 2 mm Pitch Crimp M80-4662005

The HARWIN M80-4662005 Datamate J-Tek Series Straight Panel PCB Socket is a high-reliability connector designed for critical applications requiring rugged, durable connections. It features 20 female contacts arranged in 2 rows with a 2 mm pitch, suitable for secure board-to-board interfacing in panel mount configurations.

Constructed from a polyphenylene sulphide housing, this connector offers robust mechanical strength and excellent resistance to environmental challenges. The beryllium copper alloy contacts with gold plating employ a four-finger clip design, ensuring excellent electrical continuity, shock resistance, and vibration tolerance.

Operating voltage is rated at 120V with a current capacity of 12A. The connector supports extreme temperature conditions from -55°C to 125°C, making it suitable for aerospace, military, and other harsh environments. Polarization features and fully shrouded housings prevent mis-mating, enhancing safety and reliability.

The M80-4662005 variant includes jackscrews for a secure, vibration-resistant connection. This connector is ideal for applications in aerospace, aeronautics, military systems, telecommunications, medical devices, robotics, oil and gas, and industrial equipment requiring dependable, long-life connectors.

Compact 2 mm pitch design enables efficient PCB panel mounting. Gold-plated beryllium copper contacts provide high conductivity and durability. Housings are shrouded with polarization to prevent incorrect connections. Capable of withstanding harsh environments, shock, and vibration.

Jackscrew mechanism ensures connection stability under demanding conditions. Compatible with industry standards and suitable for COTS programs. Discover a wide range of HARWIN connectors and PCB Sockets for industrial, laboratory, and commercial electronics applications at EnvMart.
