TE Connectivity DIN Rail Power Relay 24V dc Coil 3A Switching Current SPST PCJ-124D3MH,301
Specifications
| Country of Origin | China |
|---|---|
| Brand | TE Connectivity |
| Height | 15mm |
| Length | 20.4mm |
| Model | PCJ-124D3MH,301 |
| Width | 14mm |
| Mount Type | DIN Rail |
| Contact Material | Silver Alloy |
| Series | PCJ |
| Maximum Operating Temperature | 90°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 3A |
| Terminal type | Through Hole |
| Standards/Approvals | RoHS |
| Coil Resistance | 2.9kΩ |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 400V |
| Coil Power | 200mW |
Key Features
- Equipped with a sensitive 200mW coil for low power consumption.
- Mount type is designed for DIN Rail installation ensuring easy integration.
- Features silver alloy contacts providing effective electrical conductivity.
- Operates reliably between -40°C to +90°C with coil resistance of 2.9kΩ.
- Capable of switching up to 750VA power with AC voltage rating of 400V and DC voltage rating of 30V.
- Complies with RoHS standards for environmental safety.
Product Description
TE Connectivity PCJ-124D3MH,301 is a DIN Rail Power Relay designed for industrial and automation applications requiring compact and efficient power switching solutions. This relay operates with a 24V dc coil and supports a maximum switching current of 3A, making it suitable for controlling moderate loads.
The device features a single-pole single-throw (SPST) contact configuration, providing straightforward on/off switching capability. Its through-hole terminal type and DIN Rail mount allow secure and easy installation in control panels and electrical enclosures.
With a sensitive coil consuming only 200mW, this relay is energy efficient and well-suited for continuous operation in environments ranging from -40°C to +90°C. The contact material is silver alloy, which contributes to enhanced electrical conductivity and durability under switching loads up to 750VA ac and voltage limits of 400V ac and 30V dc.
The relay dimensions are compact, measuring 20.4mm in length, 14mm wide, and 15mm high, enabling space-saving designs. Its coil resistance is 2.9kΩ, ensuring stable coil operation under rated voltage.
RoHS compliance confirms that this product adheres to environmental regulations by limiting hazardous substances. It is manufactured in China under TE Connectivity's quality standards, making it a reliable component for power relay applications in industrial, automation, and electrical control systems.
Equipped with a sensitive 200mW coil for low power consumption. Mount type is designed for DIN Rail installation ensuring easy integration. Features silver alloy contacts providing effective electrical conductivity. Operates reliably between -40°C to +90°C with coil resistance of 2.9kΩ.
Compact dimensions: 20.4mm length, 14mm width, and 15mm height. Capable of switching up to 750VA power with AC voltage rating of 400V and DC voltage rating of 30V. Complies with RoHS standards for environmental safety.
This DIN Rail Power Relay is ideal for use in industrial automation, electrical control panels, building management systems, HVAC control, and other commercial electrical applications. It offers a balance of compact size, reliable performance, and energy-efficient operation, suitable for OEMs and system integrators seeking durable relay components.
Explore more Power Relay solutions and related electronic components on EnvMart to find the best fit for your application needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage for this model is 24V DC.
This relay supports a maximum switching current of 3A.
It features a single-pole single-throw (SPST) contact configuration.
The relay measures 20.4mm in length, 14mm in width, and 15mm in height.
The coil resistance is 2.9kΩ.
It operates reliably between -40°C to +90°C.
This model uses a through-hole terminal type.
The maximum AC voltage rating is 400V.
The maximum DC voltage rating is 30V.
The contacts are made of silver alloy, which enhances electrical conductivity.
The coil consumes only 200mW, making it energy efficient.
Yes, it complies with RoHS standards for environmental safety.
