ASSMANN WSW AWD Series Straight Through Hole PCB Socket, 20-Contact, 2 Row, 2.54 mm Pitch, 100V, 12A AWD 127/20/Z-T
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 100V |
| Brand | ASSMANN WSW |
| Orientation | Straight |
| Current | 12A |
| Model | AWD 127/20/Z-T |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Phosphor Bronze, Brass |
| Series | AWD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 20 |
| Contact Gender | Female |
Key Features
- Supports a current rating of 12A ensuring robust electrical performance.
- Equipped with phosphor bronze and brass contacts plated with tin for optimal conductivity and corrosion resistance.
- Constructed with polybutylene terephthalate housing for enhanced durability and mechanical stability.
- Operates reliably from -40°C to 105°C, suitable for a variety of industrial environments.
- Designed with straight orientation and female contact gender for compatibility in board-to-board connections.
- Mount type is through hole providing secure and stable PCB attachment.
- Rated for 100V voltage, ideal for standard electronic applications.
- Compliant with no specific standards approvals, engineered for general PCB socket use.
Product Description
ASSMANN WSW AWD 127/20/Z-T is a high-quality PCB socket featuring 20 contacts arranged in 2 rows with a 2.54 mm pitch, optimized for through hole solder mounting. Its design incorporates phosphor bronze and brass contact materials plated with tin, delivering excellent conductivity and corrosion resistance for industrial electronics.
The housing is made of robust polybutylene terephthalate, offering mechanical strength and resistance to high temperatures ranging from -40°C to 105°C, making it suitable for demanding applications across industrial and manufacturing environments.
This 100V rated PCB socket supports a current of up to 12A, ensuring reliable power handling in various electronic circuitry projects.
It features a straight orientation with female contacts, designed specifically for board-to-board connections with through hole mounting type, providing secure mechanical and electrical connections on printed circuit boards.
Manufactured under the AWD series by ASSMANN WSW, this socket fits a broad range of industrial, electronic manufacturing, and prototyping scenarios. Supports high current rating of 12A. Durable phosphor bronze and brass contacts with tin plating.
Polybutylene terephthalate housing for enhanced temperature and mechanical stability. Wide operating temperature range from -40°C to 105°C. Straight female contact orientation for board-to-board connectivity. Through hole mount type for secure PCB integration.
Rated for 100V voltage applications. Manufactured in China ensuring consistent quality.
This ASSMANN WSW AWD Series PCB socket is ideal for industrial electronics, power connectors, manufacturing, and prototyping tasks. Browse the PCB Sockets category at EnvMart for more high-quality connector options.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The socket supports a current rating of 12A, ensuring robust electrical performance in various applications.
It is rated for a voltage of 100V, making it suitable for standard electronic applications.
The contacts are made of phosphor bronze and brass, plated with tin for optimal conductivity and corrosion resistance.
It operates reliably within a temperature range of -40°C to 105°C, suitable for various industrial environments.
This PCB socket features 20 contacts arranged in 2 rows with a pitch of 2.54 mm.
It utilizes a through hole mounting type, providing secure and stable attachment to printed circuit boards.
The contact gender is female, designed for board-to-board connections.
The housing is constructed from polybutylene terephthalate, offering enhanced mechanical stability and durability.
The socket is engineered for general PCB socket use but does not have specific standards approvals.
The termination type for this PCB socket is solder, suitable for secure electrical connections.
This model belongs to the AWD series by ASSMANN WSW, designed for various electronic applications.
It is manufactured in China, ensuring consistent quality in production.
